Volkswagen New Beetle. Manual - part 556





Fig. 14: Identifying Glass Panel Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Cut panel seal to length after installing.

WIND DEFLECTOR, REMOVING

z

Sliding/tilting sunroof completely open.

z

Install Special Hook 3370 between edge of roof and wind deflector mounting and release wind deflector
mounting -1- from locking devices (left and right-hand sides) by pulling on Special Hook 3370.

NOTE:

Moisten edge of panel with a soapy solution to ease installation of seal.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



Fig. 15: Installing Special Hook 3370 Between Edge Of Roof And Wind Deflector Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pry wind deflector mounting out of guide rail (left and right-hand sides) with a screwdriver.

z

Remove wind deflector.

SUN BLIND, REMOVING

NOTE:

When installing, make sure that wind deflector mounting locks in carrier unit in
the prescribed position.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



z

Remove sliding/tilting sunroof glass panel, see SLIDING/TILTING SUNROOF GLASS PANEL,
REMOVING
 .

z

Slide sun blind to rear.

z

Remove forward screws -arrow- on left and right-hand sides. Pull slide out forward over the limit stop -1-



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle



Fig. 16: Removing Forward Screws On Left And Right-Hand Sides
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Slide sun blind forward.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Sunroof - New Beetle
