Volkswagen New Beetle. Manual - part 509





Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

ROOF HANDLE, REMOVING AND INSTALLING

Removing

z

Open handle -1- downward.

z

Pry cover -2- upward using a screwdriver and fold open.

z

Unscrew Phillips screws -3- and remove handle -1-.

Fig. 59: Removing Roof Handle
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

HOLD STRAPS, REMOVING AND INSTALLING

Removing

z

Pry off cover cap -1-.

z

Remove screw -2-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 60: Removing Hold Straps Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Slide cover -1- downward.

z

Remove screws -2- and take off hold strap.

Fig. 61: Removing Hold Strap
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

SILL PANEL TRIM

SILL PANEL TRIM, ASSEMBLY OVERVIEW

NOTE:

The sill panel trim strip is partially covered at front by the A-pillar lower trim and
at rear by the side panel trim. Retaining clips for these panels seat in the cut-



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



1. Sill panel trim strip

2. Clip

z

Qty. 5

3. Door inner seal

4. Carpet

Fig. 62: Identifying Sill Panel Trim
Courtesy of VOLKSWAGEN OF AMERICA, INC.

SILL PANEL TRIM STRIP, REMOVING AND INSTALLING

Removing

z

Remove A-pillar lower trim. See A-PILLAR LOWER TRIM, REMOVING AND INSTALLING .

z

Remove side panel trim. See SIDE PANEL TRIM, ASSEMBLY OVERVIEW . For convertible, see
SIDE PANEL TRIM, ASSEMBLY OVERVIEW .

z

Unclip sill panel trim strip -1- upward.

Installing

Install in reverse order of removal.

outs at the ends of the sill panel.

NOTE:

The following list refers to items in Fig. 62 .

NOTE:

z

Check clips - 2 - before installing sill panel trim strip and replace as
necessary.

z

Make sure seal -3- is seated correctly after installing sill panel trim strip.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



SILL PANEL TRIM STRIP (CONVERTIBLE), ASSEMBLY OVERVIEW

1. Sill panel trim strip

2. Clip

z

Qty. 6

3. Release lever

z

Removing and installing. See RELEASE LEVER, REMOVING AND INSTALLING .

4. Cover

5. Bolt/screw

6. Spreader nut

7. Carpet

8. Door inner seal

Fig. 63: Removing Sill Panel Trim Strip
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

The sill panel is partially covered at the rear by the side panel trim. Retaining
clips for these panels seat in the cut-outs at the ends of the sill panel.

NOTE:

The following list refers to items in Fig. 64 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle
