Volkswagen New Beetle. Manual - part 499

Fig. 1: Identifying Automatic Anti-Dazzle Interior Rear View Mirror Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

INTERIOR REAR VIEW MIRROR, REMOVING AND INSTALLING

Normal interior rear view mirror

z

Pull rear edge of trim -1- (with clock) downward off roof trim and unhook trim along forward edge.

Fig. 2: Removing Rear Edge Of Trim (With Clock) Downward From Roof Trim
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect connection -2- for interior light (and clock).

Automatic anti-dazzle interior rear view mirror

z

Pull trim (with clock) -1- to rear against the spring force -arrow A- and unhook trim along forward edge -
arrow B-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 3: Removing Trim (With Clock) To Rear Against Spring Force
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull rear edge of trim -1- downward.

z

Disconnect connections.

Interior rear view mirror (Convertible)

z

Pull rear edge of trim -1- (with clock) downward -arrow A- off roof trim and unhook trim along forward
edge -arrow B-.

Fig. 4: Removing Rear Edge Of Trim (With Clock) Downward From Roof Trim (Convertible)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect connection -2- for interior light (and clock).

Continuation for all models

z

Press interior rear view mirror -1- downward at an angle -arrow- off the retaining plate (spring clip in



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



mirror base).

Installing

Install in reverse order of removal.

Fig. 5: Pressing Interior Rear View Mirror Downward At An Angle From Retaining Plate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

STORAGE, COVERS AND TRIMS

CENTER CONSOLE UP TO 01.01, ASSEMBLY OVERVIEW

1. Center console

2. Bolt/screw

3. Bolt/screw

z

Qty. 2

4. Cover cap

z

Qty. 2

5. Bolt/screw

z

Qty. 2

6. Rubber grommet

7. Ashtray

z

Removing, see DRINK HOLDER OR ASHTRAY FROM CENTER CONSOLE UP TO 01.01,
REMOVING AND INSTALLING .

8. Drink holder

z

Qty. 2

NOTE:

The following list refers to items in Fig. 6 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



z

Removing, see DRINK HOLDER OR ASHTRAY FROM CENTER CONSOLE UP TO 01.01,
REMOVING AND INSTALLING

9. Bolt/screw

z

Qty. 2

10. Cover

11. Center console insert

12. Bolt/screw

z

Qty. 2

13. Cigarette lighter

14. Drink holder

z

Removing, see DRINK HOLDER OR ASHTRAY FROM CENTER CONSOLE UP TO 01.01,
REMOVING AND INSTALLING .

15. Bolt/screw

16. Bolt/screw

z

Qty. 2

Fig. 6: Exploded View Of Center Console And Trims
Courtesy of VOLKSWAGEN OF AMERICA, INC.

CENTER CONSOLE UP TO 01.01, REMOVING AND INSTALLING

WARNING:

Before working on electrical system: Disconnect battery Ground (GND)
strap.

NOTE:

z

The removal and installation procedures may have to be modified slightly
depending on equipment variants.

z

Obtain radio unit code before disconnecting battery.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle
