Raise rear spoiler manually. See REAR SPOILER, MANUALLY RAISING AND LOWERING .

z

Remove tailgate/trunk lid trim panel

See TAILGATE/TRUNK LID TRIM .

z

Remove rear spoiler drive, see REAR SPOILER DRIVE, REMOVING AND INSTALLING .

z

Remove six bolts/screws -1- on left and right-hand sides of top edge of tailgate -2-.

Fig. 28: Identifying Bolts/Screws On Left And Right-Hand Sides Of Top Edge Of Tailgate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unclip sealing grommets -1- on left and right-hand sides of tailgate -arrow-.

Fig. 29: Removing Sealing Grommets On Left And Right-Hand Sides Of Tailgate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Open clips -1- on left and right-hand sides.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Exterior Equipment - New Beetle



z

Remove rear spoiler assembly from vehicle. To do this unhook lower guide tube -2- and upper guide tube
-3- and pull apart on left and right-hand sides and pull apart clip -1- when taking rear spoiler assembly
off.

z

Pull cable -4- out of left and right-hand sides of lower guide tube -2- when removing the rear spoiler
assembly.

Fig. 30: Opening Clips On Left And Right-Hand Sides
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

Following work steps must be performed in addition when doing this.

z

Check condition of sealing grommets -1- before installing rear spoiler assembly to tailgate. Sealing
grommets must seal tailgate reliably. Replace hardened, porous or cracked grommets.

NOTE:

Replace damaged clips -1- when installing.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Exterior Equipment - New Beetle



Fig. 31: Checking Condition Of Rear Spoiler Sealing Grommets
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Grease guides on channel with special grease G 000 450 02 only if necessary.

z

After installing rear spoiler assembly to tailgate check parallel running and reinstate if necessary, see
PARALLEL RUNNING, CHECKING AND ADJUSTING .

z

Before installing trim to tailgate check alignment of rear spoiler -1- on tailgate and adjust if necessary.

z

Rear spoiler must seat centrally (left and right-hand sides).

z

Dimension -a- = 6 mm

z

Dimension -b- = 5 mm

Fig. 32: Checking Alignment Of Rear Spoiler On Tailgate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

To align rear spoiler, loosen bolts/screws -1- on top edge of tailgate -2- on left and right-hand sides and
then move rear spoiler assembly within oversize holes. Torque setting: Bolts/screws -1- = 6 N.m.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Exterior Equipment - New Beetle



Fig. 33: Identifying Bolts/Screws On Left And Right-Hand Sides Of Top Edge Of Tailgate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

PARALLEL RUNNING, CHECKING AND ADJUSTING

z

Raise rear spoiler manually. See REAR SPOILER, MANUALLY RAISING AND LOWERING .

Checking

Left and right-hand side channel guides -1- must be in same position (parallel). When rear spoiler is raised
dimension -a- on both channel guides -1- must be same.

NOTE:

A malfunctioning rear spoiler or a build-up of stress in the mechanics of rear
spoiler may occur if parallel running is not set correctly. When operating rear
spoiler manually rear spoiler may not stop in a raised or lowered position but
may raise and lower continuously. Cause of non parallel running is wear in
cables in area of rear spoiler drive unit or worn drive gear wheel.

NOTE:

Fig. 34 shows guide channel on left-hand side.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Exterior Equipment - New Beetle
