Volkswagen New Beetle. Manual - part 496





REAR SPOILER, ASSEMBLY OVERVIEW

1. Rear spoiler assembly

z

With channel guides, upper guide tubes and cables.

z

Grease channel guides with G 000 450 02.

z

Removing and installing, see REAR SPOILER ASSEMBLY, REMOVING AND
INSTALLING
 .

z

Checking and adjusting parallel running, see PARALLEL RUNNING, CHECKING AND
ADJUSTING
 .

2. Rear Spoiler Control Module -J223-

z

On Board Diagnostic

See REAR SPOILER, ON BOARD DIAGNOSIS (OBD) .

z

Removing and installing, see REAR SPOILER DRIVE, REMOVING AND INSTALLING .

3. Lower guide tube

z

Removing and installing, see CABLE LOWER GUIDE TUBE, REMOVING AND
INSTALLING
 .

4. Rear Spoiler Motor -V52-

z

Removing and installing, see REAR SPOILER DRIVE, REMOVING AND INSTALLING .

5. Rear Spoiler Switch -E127-

z

Below instrument panel close to steering column.

z

To manually raise and lower spoiler, see REAR SPOILER, MANUALLY RAISING AND
LOWERING
 .

6. Rear spoiler adjustment warning lamp

7. Rubber buffer

NOTE:

The following list refers to items in Fig. 24 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Exterior Equipment - New Beetle



Fig. 24: Identifying Rear Spoiler Assembly Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.


FUNCTION

Rear spoiler raises automatically when vehicle speed reaches 150 km/h (approx. 94 mph). or 70 km/h (approx.
43 mph respectively) (USA). If, at this speed sunroof is open or raised then sunroof will close automatically.

If vehicle speed drops below 130 km/h or 70 km/h (approx. 81 mph or approx. 43 mph respectively) rear spoiler
will lower automatically. Sunroof will open again.

Rear Spoiler Control Module -J223- detects malfunctions in rear spoiler system and stores these in a non-
volatile memory.

Using On Board Diagnostics the malfunctions can be read and repairs undertaken using Guided Fault Finding
(GFF).

See REAR SPOILER, ON BOARD DIAGNOSIS (OBD) .

Malfunction in rear spoiler system is indicated via rear spoiler warning lamp -arrow- when in automatic mode.
Warning lamp also lights up when rear spoiler is raised manually, see REAR SPOILER, MANUALLY
RAISING AND LOWERING
 .

Fig. 25: Identifying Rear Spoiler Warning Lamp
Courtesy of VOLKSWAGEN OF AMERICA, INC.

REAR SPOILER, MANUALLY RAISING AND LOWERING

Switch for manually raising and lowering rear spoiler (Rear Spoiler Switch -E127-) is located under instrument

WARNING:

Behavior of the vehicle can change at high speeds if spoiler does not
move into raised position.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Exterior Equipment - New Beetle



panel near steering column. Raising and lowering rear spoiler manually can only be undertaken when vehicle is
stationary or travelling less than 150 km/h or 70 km/h (approx. 81 mph or approx. 43 mph respectively).

Fig. 26: Identifying Switch For Manually Raising And Lowering Rear Spoiler
Courtesy of VOLKSWAGEN OF AMERICA, INC.

When ignition is switched on and switch is moved to position -1- rear spoiler moves to fully raised position in
one movement. Lowering is completed in several steps until limit stop is reached when switch is moved to
position -2-.

When working on rear spoiler it is sensible to raise rear spoiler fully before commencing work on unit.

REAR SPOILER DRIVE, REMOVING AND INSTALLING

Removing

z

Raise rear spoiler manually. See REAR SPOILER, MANUALLY RAISING AND LOWERING .

z

Remove tailgate lower trim.

See TAILGATE LOWER TRIM PANEL, REMOVING AND INSTALLING .

WARNING:

z

There is a danger of being caught/trapped!

z

Always make sure there is sufficient clearance when raising and
lowering rear spoiler manually.

NOTE:

Do not press raised spoiler inward (or pull outward) by hand further.

NOTE:

Rear Spoiler Control Module -J223- and Rear Spoiler Motor -V52- are integrated
in one component and are designated as rear spoiler drive in this description.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Exterior Equipment - New Beetle



z

Disconnect connector -arrow- from rear spoiler drive -4-. See Fig. 27 .

z

Loosen screw -1- and open hose clip -2- (unhook).

z

Remove bolts/screws -3- and remove drive -4- from lower guide tube -5-. Torque setting: Bolts/screws --
3- = 2.5 N.m.

Fig. 27: Rear Spoiler Drive Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

Following work steps must be performed in addition when doing this.

z

Check parallel running and reinstate if necessary before installing rear spoiler drive, see PARALLEL
RUNNING, CHECKING AND ADJUSTING
 .

z

After completing installation of the drive, lower rear spoiler completely using manual switch, then raise it
again fully using manual switch, see REAR SPOILER, MANUALLY RAISING AND LOWERING ,
to initiate drive limit stop positions.

REAR SPOILER ASSEMBLY, REMOVING AND INSTALLING

Removing

WARNING:

Before working on electrical system: Disconnect battery Ground
(GND) strap.

NOTE:

The wiring harness connections can be unhooked from the bracket on the
lower guide tubes -5-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Exterior Equipment - New Beetle
