12. Transmission housing

13. Sleeve

z

For needle roller bearing

z

Press off with 4th gear wheel and tapered roller bearing inner race. See Pressing off 4th gear
wheel with tapered roller bearing and sleeve


z

Pressing on Pressing on tapered roller bearing inner race

z

Place thrust washer on before installing (item 9)

14. Needle roller bearing

15. 5th gear wheel

z

Pull off together with 5th gear synchro-hub. See Assembly sequence

16. 5th gear synchro-ring

z

With cast locking pieces. See 5th gear synchro-ring with cast locking pieces (arrows)

z

Check for wear. See Checking 5th gear synchro-ring

17. Spring

z

Installation position. See Assembling 5th gear locking collar/synchro-hub

z

From transmission manufacture date November 05 01 the spring was changed. See CHANGED
SPRINGS FOR 5TH GEAR SYNCHRONIZER FROM TRANSMISSION MANUFACTURE
DATE NOVEMBER 11 01


18. Lock pieces (Qty. 3)

z

Installation position. See 5th gear synchronizer

z

From transmission manufacture date March 05 01 are lock pieces installed, which are inner hollow

19. 5th gear synchro-hub

z

Removing and installing. See Assembly sequence

20. 5th gear locking collar

z

Removing and installing. See Assembly sequence

21. Dished washer

z

Installation position. See Installation position of dished spring for gear wheel and 5th gear
synchro-hub securing bolts:


22. Torx socket head bolt M 10, 80 N.m

z

Installed piece on bolt head locates dished spring. See Installation position of dished spring for
gear wheel and 5th gear synchro-hub securing bolts:



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 84: Disassembling Input Shaft Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pressing out tapered roller bearing outer race



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 85: Pressing Out Tapered Roller Bearing Outer Race
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pressing in tapered roller bearing outer race



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 86: Pressing In Tapered Roller Bearing Outer Race
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pressing off tapered roller bearing inner race



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
