Volkswagen New Beetle. Manual - part 2516





Fig. 78: Removing Bearing Inner Race
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pressing Bearing Inner Ring Into Outer Ring

NOTE:

When removing and installing the inner races do not bend selector forks.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 79: Pressing Bearing Inner Ring Into Outer Ring
Courtesy of VOLKSWAGEN OF AMERICA, INC.

The inner ring must secure with the outer ring.

Pressing Inner Race In Selector Fork Onto Stop



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 80: Pressing Inner Race In Selector Fork Onto Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

The hollow in press piece 3290/1 points to bearing.

Selector Fork With Selector Segments Installed



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 81: Installing Selector Fork With Selector Segments
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Selector Fork Measurements

Application

(1)

 Dim. -a-

(mm)

1st/2nd gear selector fork

87.2 ... 87.9



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
