Volkswagen New Beetle. Manual - part 2509

Fig. 56: Driving Bushing For Starter In Flush
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Prying sleeve out with a screwdriver



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 57: Prying Sleeve Out With Screwdriver
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pulling sleeve in



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 58: Installing Sleeve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

A. Screw threaded rod from assembly tool 3066 into differential threaded piece

B. Nut M12 with washer

z

Pull sleeve in onto stop with thrust piece 3124 by turning on nut -B-.

NOTE:

When transmission is disassembled press sleeve in with thrust piece 3124
onto stop.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Pulling out sleeve and oil seal

Fig. 59: Pulling Out Sleeve And Oil Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

There is a step in inner diameter from sleeve

z

For pulling out sleeve and oil seal, apply the pulling hook VW 771/37 at the back of the step in the
sleeve.

z

While pulling out press forcibly the pulling hook VW 771/37 into the sleeve.

Driving in sleeve and oil seal



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
