Volkswagen New Beetle. Manual - part 2508





Fig. 52: Driving Needle Roller Bearing In Onto Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Secure needle roller bearing in transmission housing at three points (120° offset) with a punch.

Driving oil seal out of guide sleeve



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 53: Driving Oil Seal Out Of Guide Sleeve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Drive oil seal into guide sleeve onto stop



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 54: Driving Oil Seal Into Guide Sleeve Onto Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pulling out starter bushing



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 55: Pulling Out Starter Bushing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Mounting sequence from extractor VW 228 b

z

Turn the nut on the thread of the extractor in direction of tensioning bolt as far as possible.

z

Install extractor VW 228 b onto stop.

z

Now tighten tensioning bolt until the extractor VW 228 b is tensioned with the bushing.

Driving bushing for starter in flush



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
