Volkswagen New Beetle. Manual - part 2503





Fig. 40: Identifying 5th Gear Synchro-Ring With Cast Locking Pieces
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Drive on 5th gear synchro-hub

NOTE:

When driving make sure synchro-ring is free to move.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 41: Installing 5th Gear Synchro-Hub
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Screw-in securing bolts for synchro-hub and 5th gear wheel.

Installation position of dished spring for gear wheel and 5th gear synchro-hub securing bolts:

The outer diameter (concave side -arrows-) faces 5th gear.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 42: Locating Outer Diameter Concave Side
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Engage two gears before tightening 5th gear synchro-hub and gear wheel securing bolts (arrows). See
Fig. 22 .

z

Install 5th gear selector fork.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 43: Tightening 5th Gear Synchro-Hub And Gear Wheel Securing Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Adjusting 5th gear:

z

Engage 5th gear. Loosen bolt -1-. Press locking collar and selector fork jaws in direction of (arrow), then
tighten bolt -1- to 25 N.m.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
