2. Wire (approx. 1.2 mm diameter) 3. Securing lever Installing z Insert ignition key into lock cylinder. z Turn to "Drive" position. z Release securing lever using wire (approx. 1.2 mm diameter) and insert lock cylinder in steering lock z Remove wire out from lock cylinder and check that lock cylinder is seated properly in steering lock z Install steering column switches and steering wheel trim. See STEERING COLUMN SWITCHES . IGNITION/STARTER SWITCH, REMOVING AND INSTALLING Special tools and equipment Sealant "D2" Removing z Disconnect battery. See BATTERY, DISCONNECTING AND RECONNECTING . z Remove upper and lower steering column switch trim. See REMOVING . z Disconnect multi-pin connector from ignition/starter switch. CAUTION: Before beginning repairs on the electrical system: z Obtain the anti-theft radio security code. z Switch off all electrical consumers. z Switch off ignition and remove ignition key. z Disconnect negative ( - ) battery terminal. z When disconnecting and reconnecting battery terminals, observe all
2003 Volkswagen New Beetle GLS 1998-2004 ACCESSORIES & EQUIPMENT Lights, Switches - Exterior - New Beetle
|
