Volkswagen New Beetle. Manual - part 2445





Fig. 42: Locating Outer Diameter Concave Side
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Engage two gears before tightening 5th gear synchro-hub and gear wheel securing bolts (arrows). See
Fig. 22 .

z

Install 5th gear selector fork.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 43: Tightening 5th Gear Synchro-Hub And Gear Wheel Securing Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Adjusting 5th gear:

z

Engage 5th gear. Loosen bolt -1-. Press locking collar and selector fork jaws in direction of (arrow), then
tighten bolt -1- to 25 N.m.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 44: Adjusting 5th Gear
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check measurement: It must not be possible to slide a 0.2 mm feeler gauge between locking collar



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



and gearwheel. If necessary repeat adjustment.

z

Disengage 5th gear. Locking collar must now be in neutral position. Synchro-ring must move freely.

z

Select all gears.

z

Install transmission housing cover

z

Install flange shafts along with springs, thrust washers and tapered rings.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
