Remove pivot pins -A- on top side of transmission and transmission housing to clutch housing securing
bolts -B- in area of differential.

Fig. 25: Removing Top Side Of Transmission And Transmission Housing To Clutch Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove bolts -A-, from inside clutch housing for securing clutch housing to transmission housing.

NOTE:

Do not remove nuts -B- for output shaft bearing support.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 26: Removing Inside Clutch Housing For Securing Clutch Housing To Transmission Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Take off transmission housing, carefully pry up all round and alternating between sides on protruding
housing flange (arrows). Be careful not to damage sealing surfaces.

Fig. 27: Removing Protruding Housing Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove selector forks -A- together with selector plates.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



z

Unscrew bolt for selector mechanism for reverse gear -B-.

Fig. 28: Removing Selector Forks With Selector Plates
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



z

Remove nuts for output shaft bearing support. See ASSEMBLING , item -B-

z

Remove reverse gear -A-, input shaft -B- and output shaft -C- one after other from clutch housing.

Fig. 29: Removing Reverse Gear, Input Shaft And Output Shaft From Clutch Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Take out differential.

Assembling

z

Install differential.

z

Always replace sealing rings (arrows) for output shaft bearing support.
