Fig. 20: Removing Flange Shafts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Take out flange shafts along with springs, thrust washers and tapered rings.

z

Remove both reverse shaft support bracket bolts (arrows).



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 21: Removing Reverse Shaft Support Bracket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Transmissions up to 05.99

z

Remove selector shaft with selector mechanism cover; to do this place selector shaft in neutral position.
Then remove bolts (arrows) and pull selector shaft out of transmission housing.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 22: Removing Selector Shaft Out Of Transmission Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Transmissions as of 06.99

z

Remove selector shaft with selector mechanism cover; to do this place selector shaft in neutral position.
Then remove bolts -arrows- and pull selector shaft out of transmission housing.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 23: Removing Selector Shaft With Selector Mechanism Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continuation for all vehicles

z

Remove cover plate -A- and pivot pins -B- from underside of transmission.

Fig. 24: Removing Cover Plate And Pivot Pins From Underside Of Transmission
Courtesy of VOLKSWAGEN OF AMERICA, INC.
