Fig. 68: Turning Belt Tightening Device In Direction Of Arrow (Vehicles With Power Steering
Pump In Upper Section)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Mark direction of travel of ribbed belt with a crayon or marker before removing the ribbed belt.
Reinstalling a used belt in the opposite direction could damage the belt.

z

Remove ribbed belt.

z

Remove belt pulley hex socket head bolt.

Removing suction line and suction hose

z

Pull connector off suction line.

z

Loosen spring -type clips with special tool VAS 5024.

z

Remove suction line and suction hose

z

Clamp off return supply hose with hose clamps -3094-.

Fig. 69: Clamping Off Return Supply Hose With Hose Clamps -3094-
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



z

Clamp off suction line with hose clamps -3094-.

z

Open spring-type clip -1- and disconnect suction line.

Fig. 70: Disconnecting Power Steering Pump Suction Line (Vehicles With Power Steering Pump In
Upper Section)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unscrew banjo union bolt -2-.

{

Seal pressure line/hose with a plastic bag or similar.

z

Remove hex bolts -1- and -2-.

z

Remove pump.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 71: Removing Power Steering Pump Bolts (Vehicles With Power Steering Pump In Upper
Section)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Fill power steering pump with hydraulic oil.

Fill pump with oil via suction union.

z

Turn hub by hand until oil emits from pressure side.

z

Install power steering pump into bracket and tighten bolts to 25 N.m (18 ft lb).

z

Install suction line and spring-type clip.

The mark -arrow A- must align with casting seam -arrow-

The spring-type clip must close off mark -arrow B-.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 72: Installing Suction Line And Spring-Type Clip (Vehicles With Power Steering Pump In
Upper Section)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install new sealing rings onto Banjo union bolt.

z

Tighten Banjo union bolt to 38 N.m (28 ft lb).

The remainder of the installation is the reverse of removal.

POWER STEERING PUMP WITH HYDRAULIC LINES/HOSES, ASSEMBLY OVERVIEW

I. Vehicles with power steering pump in upper section

II. Vehicles with power steering pump in lower section

NOTE:

The following list refers to items in Fig. 73 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle
