Volkswagen New Beetle. Manual - part 2092





Removing

Vehicles with TDI engine

z

Remove noise insulation tray -arrows-.

Fig. 56: Removing Noise Insulation Tray (1.9L TDI)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove left noise insulation -arrows-.

Fig. 57: Removing Left Noise Insulation (1.9L TDI)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with 1.8 ltr. turbo and 2.0 ltr. engines

z

Remove center, left and right insulation trays:



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



See NOISE INSULATION, ASSEMBLY OVERVIEW .

Fig. 58: Removing Center, Left And Right Insulation Trays (1.8L And 2.0L)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continued for all vehicles

z

Remove right noise insulation, if installed.

Vehicles with TDI and 1.8 turbo engines

z

Remove intake air duct between charge air cooler and turbocharger.

Continued for all vehicles

z

Loosen belt pulley hex socket head bolt.

Counter-hold using hex. wrench if necessary.

Fig. 59: Removing Belt Pulley Bolt



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn tightening device in direction of arrow to relieve tension on ribbed belt.

Fig. 60: Turning Belt Tightening Device In Direction Of Arrow
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Mark direction of travel of ribbed belt with a crayon or marker before removing the ribbed belt.
Reinstalling a used belt in the opposite direction could damage the belt.

z

Remove ribbed belt.

z

Remove belt pulley hex socket head bolt.

z

Clamp off suction hose with hose clamps -3094-.

z

Open spring-type clip -3- and pull off suction hose.

Use special tool V.A.S 5024 for this.

z

Remove Banjo union bolt -4-.

{

Seal pressure line/hose with a plastic bag or similar.

z

Unbolt hex bolts -1- and -2-.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 61: Power Steering Pump Suction Hose (Vehicles With Power Steering Pump In Lower
Section)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove pump.

Installing

z

Fill power steering pump with hydraulic oil.

Fill pump with oil via suction union.

z

Turn hub by hand until oil emits from pressure side.

z

Install power steering pump into bracket and tighten bolts to 25 N.m (18.4 ft lb).

z

Install suction hose and install spring-type clip.

Fig. 62: Installing Suction Hose And Spring-Type Clip (Vehicles With Power Steering Pump In
Lower Section)

Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle
