Volkswagen New Beetle. Manual - part 2090





z

Start engine and if necessary add fluid to reservoir.

z

Turn steering wheel approx. 10 times from lock to lock.

z

Now check delivery pressure.

Requirements:

z

Ribbed belt/ribbed belt tension OK.

z

System not leaking.

z

Hoses/lines are not kinked or restricted.

{

With engine running at idle speed. Close cut-off valve (not longer than 5 seconds) and read off
pressure.

Specifications

Gasoline engines: 85...95 bar (1233 - 1378 psi)

Diesel engines: 96... 105 bar (1392 - 1523 psi)

POWER STEERING PUMP DELIVERY PRESSURE, VEHICLES WITH POWER STEERING PUMP
IN UPPER SECTION, CHECKING

Special tools and equipment

z

3094 Hose clamps

z

V.A.G 1402 Power steering test unit

z

V.A.G 1402/1 A Adapter

z

V.A.G 1402/2 Adapter

z

V.A.G 1402/6 Hose from adapter set

NOTE:

z

If the reading is higher or lower than specified, replace power steering
pump.

z

Removing and installing power steering pump, vehicles with power
steering pump in lower section. See POWER STEERING PUMP: VEHICLES
WITH POWER STEERING PUMP IN LOWER SECTION, REMOVING AND
INSTALLING .

z

If reservoir fluid level is low then check steering system for leaks.

z

For leaks at the pinion first check the lines/line connections for leaks and
if necessary tighten and wipe dry.

z

If the pinion seal or the rack seals in steering gear housing are leaking
then replace steering gear.

z

To check the rack seals loosen the hose clip on the boot and push boot to
one side.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



z

VAS 5024 Assembly pliers

Fig. 50: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove engine cover -arrows-.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 51: Removing Engine Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Clamp return hose with hose clamp 3094.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 52: Clamping Return Hose Clamp With Hose Clamp 3094
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Clamp suction hose with hose clamp 3094.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle
