Volkswagen New Beetle. Manual - part 2072





Fig. 87: Identifying Power Steering Pump In Lower Section
Courtesy of VOLKSWAGEN OF AMERICA, INC.

POWER STEERING PUMP IN UPPER SECTION, ASSEMBLY OVERVIEW

Vehicles with power steering pump in upper section

1. Mounting bracket

2. Hex bolt

z

25 N.m (18 ft lb)

3. Power steering pump

z

Checking delivery pressure. See POWER STEERING PUMP DELIVERY PRESSURE,
VEHICLES WITH POWER STEERING PUMP IN UPPER SECTION, CHECKING


z

Before installing fill with oil. See Note. See POWER STEERING PUMP, RESERVOIR,
HYDRAULIC LINES


4. Sealing rings

z

Always replace

5. Pressure line

6. Banjo union bolt

z

38 N.m (28 ft lb)

7. Suction hose

NOTE:

The following list refers to items in Fig. 88 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



8. Belt pulley

9. Hex socket head bolt

z

25 N.m (18 ft lb)

10. Ribbed belt

z

Mark the direction of travel with a crayon or marker before removing. Reinstalling a used belt in
the opposite direction could damage the belt.

z

When installing the belt, make sure that it is correctly seated in the pulleys.

z

Application see Parts catalog

z

Removing and belt routing

See RIBBED BELT, REMOVING AND INSTALLING in appropriate ENGINE MECHANICAL
article

z

Checking condition

See CHECKING CONDITION in RIBBED V-BELT, CHECKING CONDITION article

11. Tensioner for ribbed belt

Fig. 88: Identifying Power Steering Pump In Upper Section
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



DEFINITIONS

These explanations are only relevant for this assembly group: Suspension, Wheels, Steering. They are not
necessarily relevant generally.

PART NO.

Abbreviation for Part No.

STEERING ANGLE SENSOR

The steering angle sensor registers the angle that equates to the angle (lock) of the wheels and therefore the
direction selected by the driver.

HELI-COIL

A coil of spring steel which is screwed into a threaded hole and is used as the inner thread to secure a
bolt/screw.

HYTREL (POLYELASTOMER)

Substance which remains elastic especially at room temperature right up to break-up temperature.

PR. NO.

Abbreviation for Production Control Number and is used to identify optional equipment, country specific
deviations and suspension details, and other informations.

REP.-GR.

Abbreviation for repair group

SETTLING PROCESS

Plastic (non-reversible) distortion of the vehicle springs caused by the weight of the vehicle.

TOE

Offset adjustment of wheel plane to direction of travel.

TURN DIFFERENCE ANGLE

Difference between the turning lock angle of the curve inner wheel and the turning lock angle of the curve outer
wheel.

CAMBER



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Angle between wheel plane and a vertical to plane of road surface. It is positive when the top of the wheel leans
outward and negative when it leans inward.

AF

Abbreviation for across flats of wrench.

TRIPLE ROLLER JOINT

Widely used version of constant velocity joint with three rollers in the form of a star.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle
