Fig. 29: Removing Outer Tie Rod End From Steering Arm
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



A. Ball joint puller (commercial type) e.g. Kukko 128/2

z

Disconnect hoses from steering gear and seal with plastic bag and adhesive tape.

z

Seal power steering gear threaded holes with plastic sealing plugs -1- and -2-.

Fig. 30: Identifying Plastic Sealing Plugs
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove hex bolts -1- and -2-.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 31: Removing Hex Bolts From Pendulum Support
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with TDI engine



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



z

Unbolt front exhaust pipe bracket on subframe -arrows- and unhook.

Fig. 32: Removing Front Exhaust Pipe Bracket Bolts (Vehicles With 1.9L TDI Engine)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continued for all vehicles

z

Support subframe using engine/transmission jack V.A.G 1383 A.

z

Remove hex bolts -1-.

z

Remove hex bolts -2- and -3-.

z

Lower subframe using engine/transmission jack V.A.G 1383 A.

z

Remove power steering gear bolts -1-.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle
