Volkswagen New Beetle. Manual - part 2054





Fig. 22: Turning Ignition Key To Position "Ignition On" To Remove Locking Cable For Ignition
Courtesy of VOLKSWAGEN OF AMERICA, INC.


Hooking

z

Move selector lever to position "P".

z

Turn ignition key -A- to position "ignition on".

z

Push locking cable -2- into steering lock housing until clip -1- engages.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 23: Connecting Locking Cable Into Steering Lock Housing



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

IGNITION KEY LOCK, CHECKING

z

Turn ignition key to position "Ignition on".

z

Step on brake.

Must be possible to move selector lever out of "Park" position.

If this is not possible, the locking cable must be adjusted;

For 01M. See LOCKING CABLE .

For 09G. See LOCKING CABLE .

For 02E. See LOCKING CABLE .

It must only be possible to remove the ignition key when selector lever is in "Park" position!

When ignition key is in position "Ignition off" it must not be possible to move selector lever out of "Park"
position!

POWER STEERING, SERVICING

POWER STEERING GEAR, REMOVING AND INSTALLING

Special and equipment

z

3094 Hose pipe clip

z

V.A.G 1331 Torque wrench

z

V.A.G 1332 Torque wrench

z

V.A.G 1383 A Engine/transmission jack with universal transmission support V.A.G 1359/2



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 24: Identifying Special Tool And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Instructions when working on the power steering gear

Removing

NOTE:

z

Absolute cleanliness is required when working on the power steering.

z

Thoroughly clean all unions and the adjacent areas before disconnecting.

z

Place parts on a clean surface and cover if not reinstalling immediately.

z

Do not use fluffy rags that could leave line.

z

Only unpack replacement parts immediately prior to installation.

z

Only use genuine packed parts.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle
