BLEEDING SEQUENCE Only use new brake fluid conforming to US standard FMVSS 116, DOT 4. Manufacturer recommends BRAKELINE BLEEDING SEQUENCE DISC BRAKES Service Specifications DISC BRAKE SPECIFICATIONS Application Sequence All Models RR, LR, RF, LF NOTE: Manufacturer recommends changing brake fluid every 2 years. Application In. (mm) ABS Speed Sensor-To-Rotor Gap Front & Rear .003 (.08) Front Beetle FS III Brake Disc Disc Diameter 11.023 (280) Original Thickness .866 (22) Wear Limit .748 (19) Parallelism & Run-Out (1) FN 3 Brake Disc (2) Disc Diameter 11.338 (288) Original Thickness .984 (25) Wear Limit .866 (22) Parallelism & Run-Out (1) Brake Pads Original Thickness .551 (14) Wear Limit (With Pad Backing Plate) .276 (7) Rear Beetle Brake Disc Disc Diameter 9.133 (232) Original Thickness .354 (9) Wear Limit .276 (7)
2003 Volkswagen New Beetle GLS 2003 SPECIFICATIONS New Beetle
