exhaust MIL must light up.

If exhaust MIL does not light up when ignition is switched on:

z

Switch ignition off.

z

Check wire from ECM to exhaust MIL as follows:

z

Connect test box to control module wiring harness, see CONNECT TEST BOX FOR WIRING TEST

z

Bridge sockets 2+47 of test box with the respective adapter cables.

z

Switch on ignition:

exhaust MIL must light up.

If Malfunction Indicator Lamp (MIL) does not light up:

z

Switch ignition off.

z

Remove instrument cluster:

See INSTRUMENT CLUSTER, REMOVING AND INSTALLING

z

Check wire connection from Engine Control Module (ECM) to Malfunction Indicator Lamp (MIL) -K83-
according to wiring diagram.

z

Erase DTC memory of Engine Control Module (ECM), see DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA
 .

z

Generate readiness code, see READINESS CODE, GENERATING .

If no malfunctions are detected in wire from Engine Control Module (ECM) to Malfunction Indicator
Lamp (MIL):

z

Replace Motronic Engine Control Module (ECM) -J220-, see REPLACING ENGINE CONTROL
MODULE (ECM)
 .

If exhaust MIL lights up when ignition is switched on:

z

Start engine and let run at idle:

Exhaust MIL must

go out after a few seconds.

If Malfunction Indicator Lamp (MIL) does not go out:

z

Switch ignition off.

z

Remove instrument cluster:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



See INSTRUMENT CLUSTER, REMOVING AND INSTALLING

z

Connect test box to control module wiring harness, see CONNECT TEST BOX FOR WIRING TEST

z

Check wire connection between test box socket 47 and instrument cluster for short circuit to Ground
(GND) according to wiring diagram.

z

Erase DTC memory of Engine Control Module (ECM), see DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA
 .

z

Generate readiness code, see READINESS CODE, GENERATING .

If no malfunctions are detected in wire from Engine Control Module (ECM) to Malfunction Indicator Lamp
(MIL):

z

Replace Motronic Engine Control Module (ECM) -J220-, see REPLACING ENGINE CONTROL
MODULE (ECM)
 .

SELECT DIAGNOSTIC MODE

Recommended special tools and equipment:

z

VAS 5052 Vehicle Diagnostic and Information System with

z

VAS 5052/3 diagnostic cable

Fig. 11: Identifying VAS 5052 Vehicle Diagnostic And Information System
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Address word 33 - On-Board Diagnostic (OBD)

Function

Via the diagnostic tester, different diagnostic modes can be selected under "address word 33 - On-Board
Diagnostic (OBD)".



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



The following diagnostic modes monitor all components and systems which influence the emission quality.

Diagnostic mode 1: Check measured values

Requirement

z

Coolant temperature must be at least 80 °C, see PID 5, Coolant temperature.

Work procedure

z

Connect diagnostic tester, see CONNECT DIAGNOSTIC TESTER .

z

Depending on the desired operating condition:switch on ignition

or start engine and let run at idle.

z

Under address word 33, select "Diagnostic mode 1: Checking measured values."

z

Select the desired measured values "PID XX".

DIAGNOSTIC MODE 1: CHECK MEASURED VALUES

DIAGNOSTIC MODE 1: CHECK MEASURED VALUES

NOTE:

z

The specified values for the respective measuring values can be found at
the respective component- and function tests.

z

The following list only serves as an overview.

z

The measuring values are sorted according to the PID (parameter -
identifications).

PID

Display measuring values

01:

Monitoring status since erasing DTC memory

03:

Condition of the fuel system

04:

Calculated load condition value

05:

Coolant temperature

06:

Short time gasoline -air ratio bank 1

07:

Gasoline-air ratio bank 1

12:

Engine rotations per minute (RPM)

13:

Vehicle speed

14:

Valve timing adjustment at 1. cyl. to "advance"

15:

Intake Air Temperature (IAT)

16:

Air flow quantity at Mass Air Flow (MAF) sensor

17:

Throttle valve position (absolute)

PID

Display measuring values

18:

Availability status of secondary air

19:

Component location of oxygen sensors



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



z

End diagnosis and switch ignition off.

Diagnostic mode 2: Checking operating conditions

Function

This diagnostic mode displays the operating conditions at which an emission relevant malfunction was detected
and stored by the Engine Control Module (ECM).

Work procedure

z

Connect diagnostic tester, see CONNECT DIAGNOSTIC TESTER .

z

Depending on the desired operating condition:switch on ignition

or start engine and let run at idle.

z

Under address word 33, select "Diagnostic mode 2: Check operating conditions."

z

Select the desired operating condition "PID XX".

DIAGNOSTIC MODE 2: CHECKING OPERATING CONDITIONS

z

End diagnosis and switch ignition off.

Diagnostic mode 3: Check DTC Memory

Function

This diagnostic mode indicates all stored DTCs of components and systems which are emission relevant.

Malfunction Indicator Lamp (MIL) in instrument cluster lights up for a DTC entry.

21:

Bank 1 - sensor 2

28:

OBD requirement for which this vehicle is equipped

52:

Sensor current bank 1 sensor 1

NOTE:

The operating conditions are sorted by the PID (parameter-identifications).

PID

Display operating conditions

03:

Condition of the fuel system

04:

Calculated load condition value

05:

Coolant temperature

06:

Short time gasoline -air ratio bank 1

07:

Gasoline-air ratio bank 1

12:

Engine rotations per minute (RPM)

13:

Vehicle speed



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle
