Fig. 4: Identifying VAG1598/31 Test Box
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirement

z

Ignition switched off.

Work procedure

z

Remove inner cover, left plenum chamber, to do this, slide center cover -1- of plenum chamber forward
out of catch and remove from instrument panel.

Fig. 5: Removing Inner Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove three bolts -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



Fig. 6: [Removing Three Bolts]
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lift left cover -1- of plenum chamber in center of instrument panel (arrow A) and thereby unclip (front
edge clips, rear edge clamps).

z

Pull cover -1- toward vehicle center out of bracket underneath Apillar (arrow B).

z

Then disengage connector from control module and disconnect.

Fig. 7: Pulling Cover Toward Vehicle Center Out Of Bracket Underneath A Pillar
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect VAG1598/31 test box at control module wiring harness. Engine Control Module (ECM) is not
connected.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



Fig. 8: Connecting VAG1598/31 Test Box At Control Module Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

When harness connectors are disconnected from the Engine Control Module (ECM) or the battery is
disconnected, all adaptation values in the control module are erased. DTC memory content will remain intact
however. If the engine is started after this, rough, uneven idle can result. In this case, the readiness code must be
generated again, see READINESS CODE, GENERATING .

Check Malfunction Indicator Lamp (MIL) in instrument cluster

Meaning of exhaust MIL

The Malfunction Indicator Lamp (MIL) lights up when exhaust relevant malfunctions are recognized by the
Engine Control Module (ECM).

Component location of exhaust MIL

Fig. 9: Identifying ECM Harness Connector Terminals



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Blinking: There is a malfunction that causes damage to the catalytic converter in this driving condition. In
this case, vehicle must only be driven at reduced performance!

z

Continuously lit: There is a malfunction that causes increased emissions. Check DTC memory for
Motronic control module.

z

DTC memory must still be checked if there are drivability problems or customer complaints and the MIL
is not lit, since malfunctions can be stored without causing the MIL to light immediately.

Recommended special tools and equipment

z

VAG1526 multimeter or VAG1715 multimeter

z

VAG1594 connector test kit

z

Wiring diagram

Test requirement

z

The respective fuses of Malfunction Indicator Lamp (MIL) -K83- must be OK. Fuse holder is located
behind access panel at far left end of dash.

Fig. 10: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test sequence

z

Switch on ignition:

NOTE:

The Malfunction Indicator Lamp (MIL) can blink or remain lit continuously. DTC
memory must be checked in each case, see DIAGNOSTIC MODE 3: CHECK DTC
MEMORY .
