See INSTRUMENT CLUSTER .

z

Check wire connection from Engine Control Module (ECM) to Malfunction Indicator Lamp (MIL) -K83-
according to wiring diagram:

See appropriate System Wiring Diagram article.

z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA
 .

z

Generate readiness code. See READINESS CODE, GENERATING .

If no malfunctions are detected in wire from Engine Control Module (ECM) to Malfunction Indicator Lamp
(MIL):

z

Replace Motronic Engine Control Module (ECM) -J220-. See REPLACING ENGINE CONTROL
MODULE (ECM)
 .

If emissions MIL lights up when ignition is switched on:

z

Start engine and let run at idle: Emissions MIL must go out after a few seconds.

If Malfunction Indicator Lamp (MIL) does not go out:

z

Switch ignition off.

z

Remove instrument cluster:

See INSTRUMENT CLUSTER .

z

Connect test box to control module wiring harness. See TEST BOX FOR WIRING TEST,
CONNECTING
 .

Vehicles with engine code AEG

z

Check wire connection between test box socket 17 and instrument cluster for short circuit to Ground
(GND) according to wiring diagram:

See appropriate System Wiring Diagram article.

Vehicles with engine code AVH, AZG and BDC

z

Check wire connection between test box socket 47 and instrument cluster for short circuit to Ground
(GND) according to wiring diagram:

See appropriate System Wiring Diagram article.

Continuation for all vehicles



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle



z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA
 .

z

Generate readiness code. See READINESS CODE, GENERATING .

If no malfunctions are detected in wire from Engine Control Module (ECM) to Malfunction Indicator Lamp
(MIL):

z

Replace Motronic Engine Control Module (ECM) -J220-. See REPLACING ENGINE CONTROL
MODULE (ECM)
 .

DIAGNOSTIC MODE, SELECTING

Recommended special tools and equipment

z

VAS 5052 Vehicle Diagnostic and Information System with

Fig. 13: Identifying VAS 5052 Vehicle Diagnostic And Information System (Selecting Diagnostic
Mode)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAS 5052/3 diagnostic cable

Address word 33 - On-Board Diagnostic (OBD)

Function

Via the diagnostic tester, different diagnostic modes can be selected under "address word 33 - On-Board
Diagnostic (OBD)".

The following diagnostic modes monitor all components and systems which influence the emission quality.

Diagnostic mode 1: Check measured values



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle



Requirement

z

Coolant temperature must be at least 80° C, PID 5, Coolant temperature.

Work procedure

z

Connect diagnostic tester. See CONNECT DIAGNOSTIC TESTER .

z

Depending on the desired operating condition, switch on ignition or start engine and let run at idle.

z

Under address word 33, select "Diagnostic mode 1: Checking measured values."

z

Select the desired measured values "PID XX".

PID DISPLAY MEASURING VALUES (DIAGNOSTIC MODE 1)

Vehicles with engine code AEG

If DTCs are displayed in "PID 02":

NOTE:

z

The specified values for the respective measuring values can be found at
the respective component- and function tests.

z

The following list only serves as an overview.

z

The measuring values are sorted according to the PID (parameter-
identifications).

PID

Display measuring values

01:

Monitoring status since erasing DTC memory

02:

DTC

z

Only for vehicles with engine code AEG

03:

Condition of the fuel system

04:

Calculated load condition value

05:

Coolant temperature

06:

Short time gasoline-air ratio bank 1

07:

Gasoline-air ratio bank 1

12:

Engine rotations per minute (RPM)

13:

Vehicle speed

14:

Valve timing adjustment at 1. cyl. to "advance"

15:

Intake Air Temperature (IAT)

16:

Air flow quantity at Mass Air Flow (MAF) sensor

17:

Throttle valve position (absolute)

18:

Availability status of secondary air

21:

Bank 1 - sensor 2

28:

OBD requirement for which this vehicle is designed



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle



z

Repair stored malfunctions according to DTC table:

z

SAE P0xxx-DTCs. See SAE P0xxx-DTCs .

z

SAE P1xxx-DTCs. See SAE P1XXX-DTCS .

z

SAE P2xxx-DTCs. See SAE P2xxx-DTCs .

Continuation for all vehicles

z

End diagnosis and switch ignition off.

Diagnostic mode 2: Checking operating conditions

Function

This diagnostic mode displays the operating conditions at which an emission relevant malfunction was detected
and stored by the Engine Control Module (ECM).

Work procedure

z

Connect diagnostic tester. See CONNECT DIAGNOSTIC TESTER .

z

Depending on the desired operating condition: switch on ignition or start engine and let run at idle.

z

Under address word 33, select "Diagnostic mode 2: Check operating conditions."

z

Select the desired operating condition "PID XX".

PID AND DISPLAY OPERATING CONDITIONS (DIAGNOSTIC MODE 2)

Vehicles with engine code AEG

If DTCs are displayed in "PID 02":

z

Repair stored malfunctions according to DTC table:

NOTE:

The operating conditions are sorted by the PID (parameter-identifications).

PID

Display operating conditions

02:

DTC which triggered the current reception of all control module information

z

Only for vehicles with engine code AEG

03:

Condition of the fuel system

04:

Calculated load condition value

05:

Coolant temperature

06:

Short time gasoline-air ratio bank 1

07:

Gasoline-air ratio bank 1

12:

Engine rotations per minute (RPM)

13:

Vehicle speed



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle
