Volkswagen New Beetle. Manual - part 1940





Fig. 1: Identifying VAS 5052 Vehicle Diagnostic And Information System (Connect Diagnostic
Tester)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAS 5052/3 diagnostic cable

Requirements

z

The respective fuses of the Motronic fuel injection and ignition system must be OK.

Fig. 2: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Battery voltage must be at least 11.5 volts.

z

All electrical consumers such as, for example, lights and rear window defroster must be switched off.

z

Parking brake must be engaged or else daylight driving lights will be switched on.

NOTE:

Fuse holder is located behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle



z

For vehicles with automatic transmission, selector lever must be in position -P- or -N-.

z

If vehicle is equipped with an A/C system, it must be switched off.

z

Ground (GND) connections between engine and chassis must be OK.

z

Ignition switched off.

Work procedure

Connect diagnostic tester (VAS 5052) using (VAS 5052/3) diagnostic cable as follows:

z

Connect diagnostic cable connector to Data Link Connector (DLC) -arrow-.

Fig. 3: Locating Data Link Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Depending on the desired diagnostic mode, it is necessary to either switch on ignition or start engine. See
Selectable diagnostic modes under address word 33 - OBD .

z

If no display appears on diagnostic tester, check voltage supply.

Test box for wiring test, connecting

Recommended special tools and equipment e.g.:

Vehicles with 80-pin Engine Control Module (ECM, engine code AEG)

z

VAG1598/22 test box

NOTE:

z

Respective operation of the diagnostic tester:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle



Fig. 4: Identifying VAG1598/22 Test Box (80-Pin ECM)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with 121-pin Engine Control Module (ECM, engine code AVH, AZG, BDC)

z

VAG1598/31 test box

Fig. 5: Identifying VAG1598/31 Test Box (121-Pin ECM)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirement

z

Ignition switched off.

Work procedure

z

Remove inner cover, left plenum chamber, to do this, slide center cover -1- of plenum chamber forward
out of catch and remove from instrument panel.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle



Fig. 6: Removing Inner Cover, Left Plenum Chamber By Sliding Center Cover Of Plenum
Chamber Forward

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove three bolts -1-.

Fig. 7: Removing Three Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lift left cover -1- of plenum chamber in center of instrument panel (arrow A) and thereby unclip (front
edge clips, back edge clamps).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 2.0L Generic Scan Tool - New Beetle
