Volkswagen New Beetle. Manual - part 1937





z

Connect diagnostic tester. See DIAGNOSTIC TESTER, CONNECTING .

z

Start engine and let run at idle.

z

Under address word 33, select "Diagnostic mode 7: Check test results of components that are
continuously monitored".

The number of stored malfunctions or "0 malfunctions detected" is displayed.

z

End diagnosis and switch ignition off.

z

Repair stored malfunctions according to DTC table:

z

SAE P0xxx-DTCs. See SAE P0xxx-DTCs .

Diagnostic mode 9: Vehicle information

Function

In this diagnostic mode, vehicle specific diagnostic data such as e.g. the control module versions will be
displayed.

Requirement

z

There must not be any DTCs stored in DTC memory. See DIAGNOSTIC MODE 3: CHECK DTC
MEMORY
 .

Work procedure

z

Connect diagnostic tester. See DIAGNOSTIC TESTER, CONNECTING .

z

Switch ignition on.

z

Under address word 33, select "Diagnostic mode 9: vehicle information".

z

Select desired vehicle information "Test-ID XX".

Display vehicle information

DISPLAY VEHICLE INFORMATION

NOTE:

Only if engine does not start:

z

Operate starter for approx. 6 seconds. Do not switch ignition off afterward.

NOTE:

z

The DTC table is sorted by SAE codes.

z

Erase DTC memory after repairing malfunction. See DIAGNOSTIC MODE 4:
RESET/ERASE DIAGNOSTIC DATA .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle



z

End diagnosis and switch ignition off.

READINESS CODE

Function

The readiness code is an 8 digit number block that indicates the status of emission relevant diagnostics.

If a diagnostic for a system has run through successfully, the respective digit of the number block is set from 1
to 0.

Diagnostics are performed at regular intervals during normal vehicle operation. After repairing an exhaust
relevant system, the readiness code should be generated via a road test to ensure that these systems are working
according to specifications. If a malfunction is recognized during diagnostic, it is stored in DTC memory.

The readiness code is erased every time DTC memory is erased or when voltage supply is interrupted. DTC
memory should therefore only be erased when there are DTCs stored.

Read readiness code

Requirements

z

There must not be any DTCs stored in DTC memory. See DIAGNOSTIC MODE 3: CHECK DTC
MEMORY
 .

z

Coolant temperature must be at least 80 °C DIAGNOSTIC MODE 1: CHECK MEASURED
VALUES
 ; PID 5, Coolant temperature.

Work procedure

z

Connect diagnostic tester. See DIAGNOSTIC TESTER, CONNECTING .

Test-
ID

Diagnostic text

02:

Vehicle Identification Number (VIN)

(1)

example:

z

WVWSP61J22W000225

04:

Calibration identification example:

z

022906032CR 0005 Identification of control module for Diesel-Direct fuel injection

system

06

CVN (control module-check sum) example:

z

76E80034 the check sum is different for every control module version

z

No results

(1)

Display occurs only for vehicles as of model year 2002.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle



z

Start engine and let run at idle.

z

Under address word 33, select "Diagnostic mode 1: Check measured values."

z

select desired measuring value "PID 01".

z

Observe the right 8-digit number block:

If all diagnoses have run through successfully, the 8-digit number block

Specified value: 00000000 must be displayed.

Evaluation PID 01: System status-information (right 8-digit number block:)

EVALUATION PID 01: SYSTEM STATUS-INFORMATION

If a 1 is displayed instead of a 0 in the 8-digit number block:

z

Generate readiness code. See READINESS CODE, GENERATING .

Readiness code, generating

Requirements

Meaning if display position = 0
1

2 3 4 5 6 7 8

Diagnostic function

0















Exhaust gas recirculation OK



0











Oxygen sensor heater OK

z

not available/always "0"



  0









Oxygen sensors OK

z

not available/always "0"





  0







A/C system OK

z

not available/always "0"







  0





Secondary Air Injection (AIR) system OK

z

not available/always "0"









  0



EVAP canister system (tank ventilation system) OK

z

not available/always "0"











  0

Catalytic converter heater OK

z

not available/always "0"













  0

Catalytic converter OK

z

not available/always "0"



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle



z

The respective fuses of Diesel-Direct fuel injection system must be OK.

Fig. 10: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Battery voltage must be at least 11.5 Volts.

z

All electrical consumers such as, for example, lights and rear window defroster must be switched off.

z

If vehicle is equipped with an A/C system, it must be switched off.

z

Ground (GND) connections between engine and chassis must be OK.

z

There must not be any DTCs stored in DTC memory. See DIAGNOSTIC MODE 3: CHECK DTC
MEMORY
 .

Work procedure

z

Connect diagnostic tester. See DIAGNOSTIC TESTER, CONNECTING .

z

Switch ignition on.

z

Wait 5 seconds.

z

Let engine run at idle.

z

Wait 45 seconds.

z

Perform a road test.

The following operating conditions must be met during this road test:

z

With accelerator pedal depressed completely, accelerate vehicle in 3. gear or in driving mode "3" from 50
km/h to 120 km/h.

z

Drive for 2 minutes in 4. gear or in driving mode "D" on a level driving surface at a constant vehicle
speed with an engine speed of 1700 to 1900 RPM.

NOTE:

Fuse holder is located behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle
