Volkswagen New Beetle. Manual - part 1927





Work procedure

z

Connect diagnostic tester, see CONNECT DIAGNOSTIC TESTER .

z

Switch ignition on.

z

Under address word 33, select "Diagnostic mode 9: vehicle information".

z

Select desired vehicle information "Test -ID XX".

Display vehicle information

DISPLAY VEHICLE INFORMATION

z

End diagnosis and switch ignition off.

READINESS CODE

Function

The readiness code is an 8 digit number block that indicates the status of emission relevant diagnostics.

When the diagnostic for a system (e.g.: secondary air system) has run through successfully, the respective digit
of the number block is set from 1 to 0.

Diagnostics are performed at regular intervals during normal vehicle operation. After repairing an exhaust
relevant system, the readiness code should be generated via a road test to ensure that these systems are working
according to specifications. If a malfunction is recognized during diagnostic, it is stored in DTC memory.

The readiness code is erased every time DTC memory is erased or when voltage supply is interrupted. DTC
memory should therefore only be erased when there are DTCs stored.

Read readiness code

Requirements

z

There must not be any DTCs stored in DTC memory, see DIAGNOSTIC MODE 3: CHECK DTC
MEMORY
 .

z

Coolant temperature must be at least 80 °C, see DIAGNOSTIC MODE 1: CHECK MEASURED
VALUES
 ; PID 5, Coolant temperature.

Test-ID

Diagnostic text

04:

Calibration identification example:

z

06A906032LS 4745Engine Control Module (ECM) identification

06:

CVN (control module -check sum) example:

z

7608.0034the check sum is different for every control module version

z

No results



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



Work procedure

z

Connect diagnostic tester, see CONNECT DIAGNOSTIC TESTER .

z

Start engine and let run at idle.

z

Under address word 33, select "Diagnostic mode 1: Checking measured values."

z

select desired measuring value "PID 01".

z

Observe the right 8 -digit number block:

If all diagnoses have run through successfully, the 8-digit number block

Specified value: 00000000 must be displayed.

Evaluation PID 01: System status-information (right 8-digit number block:)

EVALUATION PID 01: SYSTEM STATUS-INFORMATION

If a 1 is displayed instead of a 0 in the 8 -digit number block:

z

Generate readiness code, see READINESS CODE, GENERATING .

Readiness code, generating

Requirements

z

The respective fuses of the Motronic fuel injection and ignition system must be OK. Fuse holder is
located behind access panel at far left end of dash.

Meaning if display position = 0
1

2 3 4 5 6 7 8

Diagnostic function

0















Exhaust gas recirculation OK

z

not available/always "0"



0











Oxygen sensor heater OK



  0









Oxygen sensors OK





  0







A/C system OK

z

no diagnostic/always "0"







  0





Secondary Air Injection (AIR) system OK









  0



EVAP canister system (tank ventilation system) OK











  0

Catalytic converter heater OK

z

no diagnostic/always "0"













  0

Catalytic converter OK



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



Fig. 12: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Battery voltage must be at least 11.5 volts.

z

All electrical consumers such as, for example, lights and rear window defroster must be switched off.

z

If vehicle is equipped with an A/C system, it must be switched off.

z

Ground (GND) connections between engine and chassis must be OK.

z

There must not be any DTCs stored in DTC memory, see DIAGNOSTIC MODE 3: CHECK DTC
MEMORY
 .

z

Intake air temperature 5 to 35 C, see DIAGNOSTIC MODE 1: CHECK MEASURED VALUES ; PID
15: Intake Air Temperature (IAT)

Work procedure

z

Connect diagnostic tester, see CONNECT DIAGNOSTIC TESTER .

z

Perform a road test.

The following operating condition must be met during this road test:

z

Coolant temperature must reach at least 80 C, see DIAGNOSTIC MODE 1: CHECK MEASURED
VALUES
 ; PID 5, Coolant temperature.

Observe the safety precautions that apply to road tests, see SAFETY PRECAUTIONS .

Let vehicle cool off with the ignition switched off until the following condition is met:

z

Coolant temperature approx. intake air temperature (5 to 35 °C), see DIAGNOSTIC MODE 1: CHECK
MEASURED VALUES
 ; PID 5, Coolant temperature.

z

Perform a road test anew.
