Observe safety precautions, See CHARGE AIR SYSTEM WITH TURBOCHARGER . Observe rules for cleanliness, See RULES FOR CLEANLINESS . z Unlock connection by pulling securing clamp (arrow). Fig. 4: Unlocking Connection By Pulling Securing Clamp z Remove hose/tube without assistance of tools. z When installing check for secure fit of tabs -A-. See Fig. 4 . z Use assembly tool VAS 5024 A to install spring-type clips. NOTE: All hoses of the charge air system are secured with hose clips or with quick
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Turbocharger, G-Charger - New Beetle, 1.9L 4-Cyl. - BEW
|
