Observe the safety precautions that apply to road tests, see SAFETY PRECAUTIONS .

z

Disconnect connection hose between intake manifold and fuel pressure regulator at intake manifold and
connect to T-piece of turbocharger tester (VAG1397A).

Fig. 8: Connecting To T-Piece Of Turbocharger Tester (VAG1397A)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

z

Using turbocharger tester, see operating instructions.

z

The hoses must be connected absolutely free of leaks.

z

When charge pressure is measured during the drive, a second person is
necessary to operate the turbocharger tester for safety reasons.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



z

Measure charge pressure at Wide Open Throttle (WOT):

On dynamometer

In 3rd gear or in 2nd drive mode

While driving

Vehicles with manual transmission

z

Accelerate vehicle at Wide Open Throttle (WOT) in 2nd gear

Vehicles with automatic transmission

z

Manually place vehicle in 4th gear and accelerate vehicle from low speed at Wide Open Throttle (without
kick down, transmission does not downshift any more).

Engine code APH

z

At 3000 RPM, press the "M" memory button on turbocharger tester and read out the test value.

Specified value: (absolute pressure)

1.300... 1.750 bar

Engine code AWP

z

Between 1800 to 2300 RPM, press the "M" memory button on turbocharger tester and read out the test
value.

Specified value: (absolute pressure)

1.350... 2.000 bar

Engine code AWV

z

Between 1800 to 2300 RPM, press the "M" memory button on turbocharger tester and read out the test
value.

Specified value: (absolute pressure)

1.350... 1.750 bar

z

Make sure that the pressure hose is not pinched between engine hood and
chassis.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



Continuation for all vehicles

If boost pressure is exceeded:

z

Check the Charge Air Pressure Sensor -G31-, see CHARGE AIR PRESSURE SENSOR,
CHECKING
 .

z

Check Wastegate Bypass Regulator Valve - N75-. (Throughput in hose from turbocharger via valve to
vacuum diaphragm with connector disconnected), see WASTEGATE BYPASS REGULATOR
VALVE, CHECKING
 .

z

Check for proper seating of vacuum diaphragm for wastegate bypass regulator valve at turbocharger.

z

Check vacuum diaphragm, see VACUUM DIAPHRAGM FOR WASTEGATE BYPASS
REGULATOR VALVE, CHECKING


z

Check bearing for shaft of wastegate bypass regulator valve in turbocharger for ease of movement. If
rusted solid, replace turbocharger.

z

Replace turbocharger, see item no. 6

z

Erase DTC memory of Engine Control Module (ECM), see DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA
 .

z

Generate readiness code, see READINESS CODE, GENERATING .

If boost pressure is not reached:

z

Check the Charge Air Pressure Sensor -G31-, see CHARGE AIR PRESSURE SENSOR,
CHECKING
 .

z

Check Wastegate Bypass Regulator Valve - N75-, see WASTEGATE BYPASS REGULATOR
VALVE, CHECKING
 .

z

Check bearing for shaft of wastegate bypass regulator valve in turbocharger for ease of movement. If
rusted solid, replace turbocharger.

z

Replace turbocharger, see item no. 6

z

Erase DTC memory of Engine Control Module (ECM), see DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA
 .

z

Generate readiness code, see READINESS CODE, GENERATING .

Wastegate bypass regulator valve, checking

Recommended special tools and equipment:

z

VAG1526 multimeter or VAG1715 multimeter

z

VAG1594 connector test kit

Test sequence

NOTE:

Repeat measurement if boost pressure was not fully charged or if the
difference between actual and specified values was too large.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



z

Disconnect connector -2- at Wastegate Bypass Regulator Valve -N75- (arrow).

Fig. 9: Disconnecting Connector At Wastegate Bypass Regulator Valve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Measure resistance between terminals of valve.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle
