Volkswagen New Beetle. Manual - part 1726





Fig. 5: Overview Of Exhaust Turbocharging System (Vehicles With Engine Code APH)
Courtesy of VOLKSWAGEN OF AMERICA, INC.


Overview plan of exhaust turbocharging system (Vehicles with engine code AWP, AWV)

The following list pertains to Fig. 6 .

1. Connection hose

z

From the Leak detection pump (LDP) -V144-

2. Vacuum reservoir

z

below front right wheel housing liner

3. Check-valve

4. Turbocharger

5. Vacuum diaphragm

z

For boost pressure regulator valve

6. Pressure regulator valve for crankshaft housing ventilation

7. Wastegate Bypass Regulator Valve -N75-

z

Valve is activated (pulsed) by the Engine Control Module (ECM)

z

Closed when no voltage present, limits charge pressure

z

Checking, see WASTEGATE BYPASS REGULATOR VALVE, CHECKING

8. Brake booster

9. Combination valve

z

For Secondary Air Injection (AIR) system

z

Checking, see COMBINATION VALVE, CHECKING

10. Air filter with Mass Air Flow (MAF) Sensor -G70-

11. Check-valve

12. Deceleration shut-off valve

13. Secondary Air Injection (AIR) Pump Motor -V101-

z

Checking function, see SECONDARY AIR INJECTION (AIR) PUMP MOTOR, CHECKING

14. Suction jet pump

15. Crankshaft housing ventilation

16. Fuel pressure regulator

17. Intake manifold

18. Recirculating valve for turbocharger -N249-

z

For Secondary Air Injection (AIR) system

z

Checking, see COMBINATION VALVE, CHECKING

19. Vacuum reservoir

20. Secondary Air Injection (AIR) Solenoid Valve -N112-

z

Checking, see SECONDARY AIR INJECTION (AIR) VALVE, CHECKING



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



21. Charge Air Pressure Sensor -G31-

z

Checking, see CHARGE AIR PRESSURE SENSOR, CHECKING

22. Charge air cooler

23. Evaporative Emission (EVAP) Canister Purge Regulator Valve -N80-

z

Checking, see EVAPORATIVE EMISSION (EVAP) CANISTER PURGE REGULATOR
VALVE, CHECKING


24. Connection hose

z

to EVAP canister

Fig. 6: Overview Of Exhaust Turbocharging System (Vehicles With Engine Code AWP, AWV)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Rules of cleanliness



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



When working on turbocharger, carefully observe the following "5 Rules of Cleanliness":

z

Thoroughly clean all connections and the surrounding area before disconnecting.

z

Place parts that have been removed on a clean surface and cover them. Use lint-free cloths only!

z

Carefully cover over opened components or seal, if repairs are not performed immediately.

z

Only install clean components: Only unpack replacement parts immediately prior to installation. Do not
use parts that have been stored loose (in tool boxes etc.)

z

When the system is open:Avoid working with compressed air. Do not move vehicle unless absolutely
necessary.

Safety precautions

If test and measuring equipment is required during road test, note the following:

z

Test equipment must always be secured to the rear seat and operated from there by a second person.

If test and measuring equipment is operated from the passenger seat, the person seated there could be injured in
the event of an accident involving deployment of the passenger -side airbag.

BOOST PRESSURE SYSTEM, CHECKING

Boost pressure regulation, checking

Recommended special tools and equipment e.g.:

z

V.A.G 1397 A Turbocharger Tester

WARNING:

Observe the following for all installations, especially in engine
compartment due to lack of room:

z

Route lines of all types (e.g. for fuel, hydraulic, EVAP canister
system, coolant and refrigerant, brake fluid, vacuum) and electrical
wiring so that the original path is followed.

z

Watch for sufficient clearance to all moving or hot components.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



Fig. 7: Identifying V.A.G 1397 A Turbocharger Tester
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test requirements

z

No leaks on intake or exhaust side.

z

Coolant temperature must be at least 80 °C, see DIAGNOSTIC MODE 1: CHECK MEASURED
VALUES
 ; PID 5, Coolant temperature.

Test sequence

z

Charge pressure is measured under Wide Open Throttle (WOT) while driving or on the roller type test
stand.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle
