Volkswagen New Beetle. Manual - part 1723





1998-2004 ENGINE

Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle

TURBOCHARGER G-CHARGER

CHARGE AIR SYSTEM WITH TURBOCHARGER

Removing and installing turbocharger with attachments, see TURBOCHARGER WITH ATTACHMENTS,
REMOVING AND INSTALLING
 .

Removing and installing parts of charge air cooler, see PARTS OF CHARGE AIR COOLER, REMOVING
AND INSTALLING
 .

Overview plan of exhaust turbocharging system:

z

Vehicles with engine code APH, see OVERVIEW PLAN OF EXHAUST TURBOCHARGING
SYSTEM (VEHICLES WITH ENGINE CODE APH)


z

Vehicles with engine code AWP, AWV, see OVERVIEW PLAN OF EXHAUST
TURBOCHARGING SYSTEM (VEHICLES WITH ENGINE CODE AWP, AWV)
 .

Observe rules for cleanliness, see RULES OF CLEANLINESS .

Observe safety precautions, see SAFETY PRECAUTIONS .

Turbocharger with attachments, removing and installing

NOTE:

z

All hose connections are secured with clamps.

z

Charge air system must be properly sealed.

z

Always replace self-locking nuts.

z

Charge pressure hoses and their connections must be free of grease
before re-installation.

z

VAS5024 assembly tool or VAG1921 pliers are recommended for installing
spring clips.

NOTE:

z

All hose connections are secured with clamps.

z

Charge air system must be properly sealed.

z

Always replace self-locking nuts.

z

Charge pressure hoses and their connections must be free of grease
before re-installation.

z

Components marked with * are tested via On Board Diagnostic (OBD), see
DIAGNOSTIC MODE 3: CHECK DTC MEMORY .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



Part I

The following list pertains to Fig. 1 .

1. 40 Nm

z

Coat threads with G 052 112 A3

2. Seal

z

replace

3. 10 Nm

z

Must not be loosened

4. Vacuum diaphragm

z

For boost pressure regulator valve

z

Can only be replaced together with turbocharger

z

Boost pressure regulation, checking, see BOOST PRESSURE SYSTEM, CHECKING

5. Fuse

6. Turbocharger

z

Boost pressure regulation, checking, see BOOST PRESSURE SYSTEM, CHECKING

z

The boost pressure regulator valve and vacuum diaphragm for boost pressure regulator valve are
part of the exhaust turbocharger and cannot be replaced individually.

z

Before connecting oil supply line, fill turbocharger with oil at filler tube

z

After installing turbocharger, let engine idle for approx. 1 minute without increasing engine speed.
This ensures adequate oil supply to the turbocharger.

7. O-ring

z

replace

8. 10 Nm

9. Intake manifold

10. Seal

z

replace

z

Note installed position

11. 20 Nm

12. Heat shield

13. 10 Nm

14. Banjo fitting, 30 Nm

15. Oil supply line

16. 30 Nm

z

replace

z

Coat threads and bolt head contact surface with G 052 112 A3

17. Exhaust manifold

18. Seal



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



z

replace

z

Note installed position

19. 20 Nm

20. Banjo fitting, 30 Nm

21. 25 Nm

z

replace

z

Coat threads with G 052 112 A3

22. Banjo fitting, 35 Nm

23. Coolant return line

24. 25 Nm

25. Spacer sleeve

26. Banjo fitting, 35 Nm

27. 10 Nm

28. Coolant supply line

29. Banjo fitting, 35 Nm

30. 30 Nm

z

use only original bolts from parts catalog

31. Bracket

z

Between turbocharger and cylinder block

32. 25 Nm

33. Seal

z

replace

34. Seal

z

replace

35. 10 Nm

36. Oil return line

z

To oil pan

37. 10 Nm

38. 10 Nm

z

Do not change orientation

z

Must not be loosened



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



Fig. 1: Exploded View Of Turbocharger With Attachments
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Part II

Vehicles with engine code APH

Vehicles with engine code AWP, AWV, see VEHICLES WITH ENGINE CODE AWP, AWV

The following list pertains to Fig. 2 .

1. Deceleration shut-off valve

z

Checking, see DECELERATION SHUT-OFF VALVE, CHECKING

2. Connection hose

z

To Recirculating valve for turbocharger -N249-*



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle
