Fig. 137: Connecting VAGXS 1598/31 Test Box To Control Module Wiring Harness Checking voltage supply terminal 30 z Measure supply voltage between test box sockets 1 + 62 using multimeter and adapter cables from VAG Specification: at least 11.5 V If the specification is not obtained: z Check wiring connections to relay plate according to Electrical Wiring Diagram. z Check DTC Memory, if necessary, repair any malfunctions and then Erase DTC Memory, see DTC
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE PERFORMANCE Multiport Fuel Injection (MFI) , 1.8L AWP, AWV - New Beetle
|
