z Press buttons -0-, -0- and -1- for "Display group number 1" and confirm entry with -Q- button. Indicated on display (1 to 4 - Display zones) Fig. 98: Identifying Scan Tool Display - Checking Idle Speed (3 Of 3) z Check adjustment conditions for basic setting in display zone 4. Specification: 1x111111 Significance of the numbers, see CHECKING IDLE SPEED DISPLAY GROUP 1: IDLING TEST NOTE: In the "System in basic setting" function the EVAP canister purge
Display zones 1 2 3 4 Display group 1: Idling test xxxx RPM xxx.x °C xx.x % xxxxxx Indicated Engine speed (in steps of 40) Engine Coolant Temperature (ECT) Oxygen sensor control before Three Way Catalytic Converter (TWC) Adjustment conditions Working 0 to 6800 -48.0 to 143.0 C -10.0 to 10.0% - Specification 760 to 810 RPM (1)
80.0 to 115.0 C Value must fluctuate by at least 2% in -10.0 to 10.0% 1x111111
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE PERFORMANCE Multiport Fuel Injection (MFI) , 1.8L AWP, AWV - New Beetle
|
