260

1980-82

...

...

...

...

...

...

740

1985-91

...

...

...

...

...

...

760

1983-90

...

...

...

...

...

...

780

1986-90

...

...

...

...

...

...

850

1992-97

...

...

...

...

...

...

940

1991-95

...

...

...

...

...

...

960

1992-97

...

...

...

...

...

...

Coupe

1990-91

...

...

...

...

...

...

C70 & S70

1998-2003

...

...

...

...

(1)

...

Cross Country

2003

...

...

...

...

(4)

(2)

S40 & V40

2000-03

...

...

...

...

(3)

...

S60

2001-03

...

...

...

...

(2)

...

S80

1999-2003

...

...

...

...

(2)

...

S90

1997-98

...

...

...

...

...

...

V70

1998-2000
AWD

...

...

...

...

(4)

(1)

1998-2000 2WD

...

...

...

...

(1)

...

2001-03 AWD

...

...

...

...

(4)

(3)

2001-03 2WD

...

...

...

...

(2)

...

V90

1997-98

...

...

...

...

...

...

XC90

2003 AWD

...

...

...

...



1998 Chevrolet Pickup C1500

GENERAL INFORMATION Traction Control, 4WD & AWD Identification & Disable Procedures - All Models



YUGO

YUGO

(4)

(2)

2003 2WD

...

...

...

...

(2)

...

(1)

Press TRACS or STC switch located on dash. Indicator light will illuminate when
system is disabled.

(2)

Press STC/DSTC switch on center console and hold down for more than half a
second. The light in the switch will go off when system is disabled.

(3)

Press STC, DSA or DSTC switch located on dash to disable system. Indicator light
will illuminate when system is disabled. On models equipped with winter/wet
driving mode, depress the "W" switch on center console. The LED on switch will
turn off when winter/wet driving mode is disengaged.

(4)

Cannot be shifted to 2WD.

Application  FWD RWD  Part Time 4WD  Full Time 4WD  AWD TCS  Do Not Test
GV & GVL

1985-91

...

...

...

...

...

...



1998 Chevrolet Pickup C1500

GENERAL INFORMATION Traction Control, 4WD & AWD Identification & Disable Procedures - All Models



GENERAL INFORMATION

Clutch Trouble Shooting

ALL MODELS

CLUTCH TROUBLE SHOOTING

Problem & Possible Cause

Action

Clutch Chatters/Grabs

Incorrect Pedal Adjustment

Adjust Free Play

Worn Input Shaft Spline

Replace Input Shaft

Binding Pressure Plate

Replace Pressure Plate

Binding Throw-Out Lever

Check Throw-Out Lever, Check Throw-Out

Bearing, Check Bearing Retainer

Uneven Pressure Plate Contact With
Flywheel

Align/Replace Worn Parts

Transmission Misaligned

Align Transmission

Worn Pressure Plate

Replace Clutch Assembly

Oil-Saturated Disc

Replace Clutch Assembly, Repair Oil Leak

Loose Engine Mounts

Replace Engine Mounts

Clutch Pedal Sticks Down

Clutch Cable Binding

Replace Clutch Cable

Weak Pressure Plate Springs

Replace Clutch Assembly

Binding Clutch Linkage

Lubricate Linkage

Broken Clutch Pedal Return Spring

Replace Return Spring

Clutch Will Not Release

Oil-Saturated Disc

Replace Clutch Assembly, Repair Oil Leak

Defective Disc Face

Replace Clutch Assembly

Disc Sticking on Input Shaft Splines

Replace Disc/Input Shaft

Binding Pilot Bearing

Replace Pilot Bearing

Faulty Clutch Master Cylinder

Replace Master Cylinder

Faulty Clutch Slave Cylinder

Replace Slave Cylinder

Blown Clutch Hose

Replace Hose

Sticky Throw-Out Bearing Sleeve

Clean/Lube Sleeve

Clutch Cable Binding

Replace Clutch Cable

Broken/Loose Bellhousing

Check Bellhousing

Rattling/Squeaking

Broken Throw-Out Lever Return
Spring

Replace Return Spring

Faulty Throw-Out Bearing

Replace Throw-Out Bearing



1998 Chevrolet Pickup C1500

GENERAL INFORMATION Clutch Trouble Shooting





1998 Chevrolet Pickup C1500

GENERAL INFORMATION Clutch Trouble Shooting



Faulty Clutch Disc

Replace Clutch Disc

Faulty Pilot Bearing

Replace Pilot Bearing

Worn Throw-Out Bearing

Replace Throw-Out Bearing

Dry Bearing Retainer Slide For
Throw-Out Bearing Sleeve

Lubricate Slide

Slipping

Faulty Pressure Plate

Replace Clutch Assembly

Worn Clutch Disc

Replace Clutch Assembly

Incorrect Alignment

Realign Clutch Assembly

Faulty Clutch Slave Cylinder

Replace Slave Cylinder

No Pedal Pressure

Leaky Hydraulic System

Check Clutch Master Cylinder, Check Clutch

Slave Cylinder

Check Clutch Hose

Broken Clutch Cable

Replace Clutch Cable

Faulty Throw-Out Lever

Replace Throw-Out Lever

Broken Clutch Linkage

Repair Clutch Linkage

Noisy Clutch Pedal

Faulty Safety Switch

Check/Replace Switch

Noisy Self-Adj. Ratchet

Replace Ratchet

Dry Throw-Out Bearing

Replace Throw-Out Bearing

Dry Pilot Bearing

Replace Pilot Bearing

Worn Input Shaft

Replace Input Shaft
