Fig. 68: Connecting Diagnostic Cable VAS 5051/1 Or VAS 5051/3 To Data Link Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Start engine and run at idling speed.

Only when the engine does not start:

z

Switch on ignition.

Selecting operating mode

z

Press button on screen for "Vehicle self-diagnosis".

Selecting vehicle system

z

Press button "01 - Engine electronics" on screen.

The control module identification, the engine control module coding as well as the chassis number and
immobilizer identification number are shown on the screen.

z

Press --> key.

z

Press "Print" key.

Selecting diagnostic function

NOTE:

A print-out can be produced if required. Press the "Print" button.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Press button "02 - Interrogating fault memory" on screen.

z

"No fault detected" appears on screen if no faults are stored in engine control module.

z

If faults are stored in engine control module they will appear on screen listed one below another.

z

Press <-- key.

z

Press button "05 - Erase fault memory" on screen.

z

Press function 06-"End output".

z

Generate readiness code if fault memory has been erased. See COMPONENTS AND FUNCTIONS,
ADAPTING


NOTE:

Generate the readiness code if an emissions test is to be performed after
erasing the fault memory or after disconnecting the engine control module from
permanent positive. See COMPONENTS AND FUNCTIONS, ADAPTING .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



1998-2004 ENGINE PERFORMANCE

Multiport Fuel Injection (MFI) , 1.8L AWP, AWV - New Beetle

MULTIPORT FUEL INJECTION (MFI)

FUEL INJECTION SYSTEM, SERVICING

Component locations, overview

The following list pertains to Fig. 1 .

1. Heated Oxygen Sensor (HO2S) -G39-, 50Nm

z

Location: before Three Way Catalytic Converter (TWC)

2. 6-pin connector

z

Black

z

Terminals gold plated

z

For Heated Oxygen Sensor (HO2S) before Three Way Catalytic Converter (TWC) -G39- and
oxygen sensor heater -Z19-

z

Right on underside of vehicle

3. Oxygen Sensor (O2S) after Three Way Catalytic Converter (TWC) - G130-, 50Nm

z

Location: behind Three Way Catalytic Converter (TWC)

4. 4-pin connector

z

Black

z

Terminals 3 and 4 gold-plated

z

For Oxygen Sensor (O2S) after Three Way Catalytic Converter (TWC) - G130- and oxygen sensor
heating - Z29-

z

Right on underside of vehicle

5. Camshaft position (CMP) sensor - G40-

z

See IGNITION SYSTEM COMPONENTS, REMOVING AND INSTALLING , item 7

6. Secondary Air Injection (AIR) Solenoid Valve -N112-

z

Secondary air system:

See SECONDARY AIR INJECTION (AIR) SYSTEM

7. Recirculating valve for turbocharger -N249-

z

Checking charge pressure system

See TURBOCHARGER, G-CHARGER

8. Ignition coils with power output stage (-N70-, -N127-, -N291-, -N292-)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Multiport Fuel Injection (MFI) , 1.8L AWP, AWV - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Multiport Fuel Injection (MFI) , 1.8L AWP, AWV - New Beetle



z

See IGNITION SYSTEM COMPONENTS, REMOVING AND INSTALLING , item 2

9. Wastegate Bypass Regulator Valve - N75-

z

Checking charge pressure system

See TURBOCHARGER, G-CHARGER

10. Protective housing

z

For Secondary Air Injection (AIR) Pump Relay -J299-

z

Secondary air system

See SECONDARY AIR INJECTION (AIR) SYSTEM

11. Motronic Engine Control Module (ECM) -J220-

(Motronic Motronic Engine Control Module (ECM) -J220- -J220-)

z

Location: below inner cover of plenum chamber, left side in driver compartment

12. O-ring

z

Replace if damaged

13. Engine Coolant Temperature (ECT) sensor -G62-

z

For Motronic Engine Control Module (ECM) -J220-

z

With Engine Coolant Temperature (ECT) gauge sensor -G2-

z

If necessary release pressure in cooling system before removing

z

Checking, see ENGINE COOLANT TEMPERATURE (ECT) SENSOR -G62-, CHECKING

14. Retaining clip

z

Check for secure seating

15. Mass Air Flow (MAF) sensor -G70-

16. Valve 1 for camshaft adjustment - N205-

z

Servicing valve train; checking camshaft adjustment

See ENGINE - CYLINDER HEAD, VALVETRAIN

17. Fuel pressure regulator

18. Injectors -N30- to -N33-

19. 10 Nm

20. Engine Speed (RPM) Sensor -G28-

z

Checking, see ENGINE SPEED (RPM) SENSOR, CHECKING

21. O-ring

z

Replace

22. 20 Nm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Multiport Fuel Injection (MFI) , 1.8L AWP, AWV - New Beetle
