Volkswagen New Beetle. Manual - part 1588





Fig. 53: Identifying Fuse 28 (Fuel Pump)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect remote control V.A.G 1348/3A with adapter cable V.A.G 1348/3-2 to contact 28a to fuel pump
and Battery positive (+).

NOTE:

Fuse holder is behind access panel at far left end of dash.

WARNING:

Fuel system is under pressure! Before opening the system place a
cloth around the connection. Then release pressure by carefully
loosening the connection.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 54: Connecting Remote Control V.A.G 1348/3A With Adapter Cable V.A.G 1348/3-2
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull off supply line -1- (black markings) and collect leaking fuel with a cloth.

Fig. 55: Pulling Off Fuel Supply Line (Engine Codes BEV And BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect pressure gauge V.A.G 1318 with adapter V.A.G 1318/23 and V.A.G 1318/17 to fuel supply line.

NOTE:

To do this slide safety ring -2- into the union -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 56: Connecting Pressure Gauge V.A.G 1318 With Adapter V.A.G 1318/23 And V.A.G 1318/17
To Fuel Supply Line

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Close pressure gauge shut-off tap. Lever is diagonal to direction of flow (position -B-).

z

Operate remote control V.A.G 1348/3A for approx. 10 seconds to build up a system pressure of approx 4
bar.

z

Observe pressure drop on gauge.

z

Over a duration of 30 minutes pressure must not drop below 3.2 bar

If the pressure drops further:

z

Check line connections for leaks.

If no line connection fault is detected:

z

Replace fuel pressure regulator.

INTAKE MANIFOLD CHANGE-OVER, CHECKING

Engine codes BDC, BGD

This check need only be performed when there is a reduction in available torque, i.e. issues with engine
elasticity and pulling power on acceleration etc.

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

V.A.G 1390 Hand vacuum pump

Fig. 57: Identifying V.A.G 1390 Hand Vacuum Pump
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1368 Vacuum tester



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 58: Identifying V.A.G 1368 Vacuum Tester
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Work sequence

z

Check that vacuum lines are correctly installed and not interchanged. See INTAKE MANIFOLD
UPPER PART, DISASSEMBLING AND ASSEMBLING
 and INTAKE MANIFOLD LOWER
PART, DISASSEMBLING AND ASSEMBLING
 .

z

Check vacuum hoses for porosity.

z

Check vacuum system for leaks.

Checking vacuum actuator in intake manifold upper part for leaks

z

Pull vacuum hose to variable intake manifold actuator (arrow) off intake manifold change-over valve -1-.

Fig. 59: Removing Intake Manifold Change-Over Valve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

The variable intake manifold change-over actuator is integrated in the



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
