Volkswagen New Beetle. Manual - part 1586





Fig. 44: Disconnecting Fuel Return Hose And Fuel Supply Hose (Engine Code BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Connect pressure gauge V.A.G 1318 to fuel supply line/hose and to hose to fuel rail using adapters
1318/9 and 1318/17.

Fig. 45: Connecting Pressure Gauge V.A.G 1318 To Fuel Supply Line/Hose And Hose To Fuel Rail
Using Adapters 1318/9 And 1318/17

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Open shut-off tap on pressure gauge. Handle points in direction of flow.

z

Reinstall fuse 28 (fuel pump) in fuse holder.

z

Start engine and run at idling speed.

z

Measure fuel pressure.

z

Specification: Approx. 2.5 bar

z

Pull vacuum hose -1- off fuel pressure regulator -2-.

z

Fuel pressure must increase to approx. 3.0 bar

NOTE:

Press locking ring inward to release fuel line.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 46: Removing Vacuum Hose Off Fuel Pressure Regulator
Courtesy of VOLKSWAGEN OF AMERICA, INC.

If the specification is not obtained:

z

Check delivery rate of fuel pump. See FUEL PUMP, CHECKING

If the specification is obtained:

z

Switch off ignition.

z

Check for leaks and holding pressure. Watch pressure drop on gauge.

z

After 10 minutes there must be a residual pressure of at least 2.0 bar

If the holding pressure drops below 2 bar:

z

Start engine and run at idling speed.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Switch ignition off after the pressure has built-up. Simultaneously, close pressure gauge V.A.G 1318 cut-
off tap. Handle is across through-flow direction (arrow).

Fig. 47: Closing Pressure Gauge V.A.G 1318 Cut-Off Tap
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Observe pressure drop on gauge.

If the pressure does not drop:

z

Check non-return valve of fuel pump. See FUEL PUMP, CHECKING

If the pressure drops again:

z

Check pressure gauge for leaks.

z

Check line connections, O-rings on fuel rail and injectors for leaks.

If no leaks can be found:

z

Replace fuel pressure regulator

z

Erase fault memory to return learned values to a neutral (default) position. See ENGINE CONTROL
MODULE FAULT MEMORY, INTERROGATING AND ERASING
 .

Engine codes BEV, BGD

NOTE:

Place a cloth around the connections to be loosened again and remove fuse 28
(fuel pump) from fuse holder before removing the pressure gauge.

NOTE:

z

The fuel pressure regulator regulates the fuel pressure to approx. 4 bar.

z

The fuel pressure regulator is located at the fuel filter (next to the fuel
tank).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Special tools, equipment, testers, measuring instruments and auxiliary items required

z

V.A.G1318 Pressure gauge

z

1318/9 Adapter

z

1318/17 Adapter

z

1318/23 Adapter

z

V.A.G 1348/3 A Remote control

Fig. 48: Identifying Special Tools, Equipment, Testers And Measuring Instruments (Engine Codes
BEV And BGD)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Work sequence

z

Remove cover in front of fuse holder.

z

Remove fuse 28 (fuel pump) from fuse holder.

WARNING:

Fuel system is under pressure! Before opening the system place a
cloth around the connection. Then release pressure by carefully
loosening the connection.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
