Fig. 5: Locating Fuse 32 Test Data, Spark Plugs SPARK PLUGS TEST DATA Check Camshaft Position (CMP) sensor NOTE: By removing fuse 32, voltage supply to the fuel injectors is interrupted. NOTE: Fuse holder is located behind access panel at far left end of dash. Engine Code AEG AVH, AZG, BDC Ignition sequence 1-3-4-2 1-3-4-2 Spark plugs
VW/Audi 101 000 033 AA 101 000 062 AB Manufacturer code BKUR 6ET-10 PZF R5D-11 Tightening torque 30 Nm 30 Nm Spark plug gap max. 0.9 to 1.1 mm max. 0.9 to 1.1 mm Engine Control Module (ECM) (1) System identification Motronic M5.9.2 Motronic ME7.5 Terminals at Engine Control Module 80 121 Part number See Parts catalog See Parts catalog Engine speed (RPM) limitation starting at approx. 6300 RPM starting at approx. 6300 RPM . (1) Replacing Engine Control Module (ECM). See REPLACING ENGINE CONTROL MODULE
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle
|
