If the specification is not obtained, see Evaluating display group 15 display zones 1 to 3 and display group
16 display zone 1 - total number of catalyst damaging misfires Cyl. 1 to Cyl. 4

z

Press --> button.

z

Press buttons -0- and -6- for "End output" function and confirm input with -Q- button.

z

Switch off ignition.

Evaluating display group 14, display zone 3 - total number of catalyst damaging misfires

EVALUATING DISPLAY GROUP 14, DISPLAY ZONE 3 - TOTAL NUMBER OF CATALYST
DAMAGING MISFIRES

Evaluating display group 15 display zones 1 to 3 and display group 16 display zone 1 - total number of catalyst damaging misfires
Cyl. 1 to Cyl. 4

EVALUATING DISPLAY GROUP 15 DISPLAY ZONES 1 TO 3 AND DISPLAY GROUP 16 DISPLAY
ZONE 1 - TOTAL NUMBER OF CATALYST DAMAGING MISFIRES CYL. 1 TO CYL. 4

Indicated

Catalyst damaging misfires Cyl. 4

- -

Misfire status recognition

Working range

0--65000

- -

-

Specification

0

- -

activated

Appears on
display

Possible malfunction cause

Malfunction elimination

> 0

z

Spark plug

malfunctioning

z

Ignition coil with power

output stage

malfunctioning

z

Check spark plugs, see IGNITION/GLOW PLUG

SYSTEM

z

Check ignition coils with power output stage, see
IGNITION COILS WITH POWER OUTPUT

STAGE, CHECKING



z

Fuel injector

malfunctioning

z

Check fuel injectors, see FUEL INJECTORS,

CHECKING

Appears on
display

Possible malfunction cause

Malfunction elimination

> 0

z

Spark plug

malfunctioning

z

Ignition coil with power

output stage

malfunctioning

z

Fuel injector

malfunctioning

z

Check spark plugs, see IGNITION/GLOW

PLUG SYSTEM

z

Check ignition coils with power output stage, see
IGNITION COILS WITH POWER OUTPUT

STAGE, CHECKING

z

Check fuel injectors, see FUEL INJECTORS,

CHECKING



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Ignition/Glow plug system, 1.8L AWP, AWV - New Beetle



1998-2004 ENGINE PERFORMANCE

Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle

IGNITION/GLOW PLUG SYSTEM

IGNITION, SERVICING

General notes on ignition system

z

This section deals specifically with ignition-related components. The other components of the injection
and ignition system. See MULTIPORT FUEL INJECTION (MFI) .

z

For the electric components to work properly, a voltage of at least 11.5 V is required.

z

The battery must only be disconnected and connected with the ignition switched off, since the Engine
Control Module (ECM) can otherwise be damaged.

z

The Engine Control Module (ECM) is equipped with an On Board Diagnostic (OBD)

z

Components marked with * are tested via On Board Diagnostic (OBD). See DIAGNOSTIC MODE 3:
CHECK DTC MEMORY .

z

It is possible that the control module will recognize a malfunction and store a DTC during some tests.
Therefore the following work steps must be performed in the mentioned sequence after ending all tests
and repairs.

{

Check DTC memory. See DIAGNOSTIC MODE 3: CHECK DTC MEMORY .

{

Erase DTC memory. See DIAGNOSTIC MODE 4: RESET/ERASE DIAGNOSTIC DATA .

{

For completion, generate readiness code. See READINESS CODE, GENERATING .

Parts of ignition, removing and installing:

z

Vehicles with engine code AEG. See PARTS OF THE IGNITION, REMOVING AND
INSTALLING (VEHICLES WITH ENGINE CODE AEG) .

z

Vehicles with engine code AVH, AZG, BDC. See PARTS OF THE IGNITION, REMOVING AND
INSTALLING (VEHICLES WITH ENGINE CODE AVH, AZG, BDC) .

Safety precautions. See SAFETY PRECAUTIONS .

Test data, spark plugs. See TEST DATA, SPARK PLUGS .

Parts of the ignition, removing and installing (Vehicles with engine code AEG)

NOTE:

Engine Control Module (ECM) with harness connectors. See item 5 in
OVERVIEW OF COMPONENT LOCATIONS (VEHICLES WITH ENGINE CODE
AEG) .

NOTE:

The following list refers to Fig. 1 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle



1. 10 Nm

2. Ignition wire

z

4 to 8 k ohm

z

with interference suppression connector and spark plug connector

3. Spark plug, 30 Nm

z

Type and spark plug gap. See TEST DATA, SPARK PLUGS .

4. 20 Nm

z

Tightening torque affects function of Knock Sensor (KS)

5. Knock Sensor (KS) 2 (G66)*

z

Component location. See item 14 in OVERVIEW OF COMPONENT LOCATIONS
(VEHICLES WITH ENGINE CODE AEG) .

z

Terminals of sensor and connector are gold-plated

z

contact surfaces between knock sensor and cylinder block must be free of corrosion, dirt and grease

z

Checking. See CHECK KNOCK SENSORS .

6. Connector

z

brown, 2-pin

z

For Knock Sensor (KS) 2 -G66-

z

before disconnecting, mark allocation of connector to component

z

Terminals of sensor and connector are gold-plated

7. Knock Sensor (KS) 1 (G61)*

z

Component location. See item 15 in OVERVIEW OF COMPONENT LOCATIONS
(VEHICLES WITH ENGINE CODE AEG) .

z

Terminals of sensor and connector are gold-plated

z

contact surfaces between knock sensor and cylinder block must be free of corrosion, dirt and grease
Checking. See CHECK KNOCK SENSORS .

8. Connector

z

black, 2-pin

z

For Knock Sensor (KS) 1 -G61-

z

before disconnecting, mark allocation of connector to component

z

Terminals of sensor and connector are gold-plated

9. Camshaft Position (CMP) sensor (G40)*

z

Component location. See item 17 in OVERVIEW OF COMPONENT LOCATIONS
(VEHICLES WITH ENGINE CODE AEG) .

z

Terminals of sensor and connector are gold-plated

z

Checking. See CHECK CAMSHAFT POSITION (CMP) SENSOR .

10. Connector

z

black, 3-pin

z

For Camshaft Position (CMP) sensor 2 -G40-



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 2.0L Generic Scan Tool - New Beetle



z

Terminals of sensor and connector are gold-plated

11. Connector

z

Black, 4-pin

z

for Ignition Coil -N152-

12. Ignition Coil -N152-*

z

Component location. See item 12 in OVERVIEW OF COMPONENT LOCATIONS (VEHICLES
WITH ENGINE CODE AEG) .

z

with marking for ignition wires: A = Cylinder 1B = Cylinder 3C = Cylinder 2D = Cylinder 4

z

Checking. See CHECKING IGNITION COIL (VEHICLES WITH ENGINE CODE AEG) .

Fig. 1: Identifying Parts Of Ignition System (Vehicles With Engine Code AEG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Parts of the ignition, removing and installing (Vehicles with engine code AVH, AZG, BDC)

z

Vehicles with engine code AVH, AZG. See item 11 in OVERVIEW OF COMPONENT LOCATIONS
(VEHICLES WITH ENGINE CODE AVH, AZG) .

z

Vehicles with engine code BDC. See item 12 in OVERVIEW OF COMPONENT LOCATIONS
(VEHICLES WITH ENGINE CODE BDC) .

1. Ignition wire

z

4 to 8 k ohm

z

with interference suppression connector and spark plug connector

NOTE:

Engine Control Module (ECM) with connectors:

NOTE:

The following list refers to Fig. 2 .
