If the specification is obtained: z Press --> button. z Press buttons -0- and -6- for function "End output" and confirm entry with -Q- button. z Switch off ignition. Continuation: If the specifications are not obtained: z Press --> button. z Press buttons -0- and -6- for function "End output" and confirm entry with -Q- button. z Switch off ignition. Checking resistance of Knock Sensors (KS) z Disconnect 2-pin harness connector to Knock Sensor (KS) 1 - G61- (item no. 1 ) and/or 2-pin harness Display zones 2 3 4 Display group 28: ignition, knock control xxxx RPM xxx.x % xxx.x °C Test OFF/Test ON Syst. OK. Syst. n. OK. Indicated Engine speed (in steps of 40) Engine load Engine Coolant Temperature OBD condition and OBD result Working 0 to 6800 RPM 0.0 to 175.0% -40.0 to 115.0 ° C - Specification at least 2200 RPM > 40.0% 85.0 to 115.0 ° C Syst. OK. - - - If the specifications are not achieved, see CHECKING WIRING , Continuation
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Ignition/Glow plug system, 1.8L AWP, AWV - New Beetle
|
