Fig. 5: Measuring Voltage Between CMP Sensor Harness Connector Terminals 1 And 3
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Switch on ignition.

Specification: min. 4.5 V

z

Switch off ignition.

If no voltage is present:

z

Remove inner plenum chamber cover, left:

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

z

Connect test box V.A.G 1598/31 to control module wiring harness. Engine control module is not
connected by this action.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L APH - New Beetle



Fig. 6: Connecting Test Box V.A.G 1598/31
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open circuit between test box and connector using wiring diagram.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L APH - New Beetle



Fig. 7: Identifying CMP Sensor Harness Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Contact 1 + socket 98

z

Contact 2 + socket 86

z

Contact 3 + socket 108

Wire resistance: Max. 1.5 ohm

z

Additionally check wires for short to one another.

Specification: INFINITY ohm

If no malfunctions in wiring are detected and voltage was present between contacts 1 + 3:

z

Replace Camshaft Position (CMP) sensor -G40-, see item 7 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L APH - New Beetle



z

Check DTC memory, if necessary, repair any malfunctions and then erase DTC memory, see
DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING AND ERASING .

z

Read readiness code, see READINESS CODE, DISPLAYING . If DTC memory has been erased or
engine control module was disconnected from permanent positive, readiness code must be generated
again, see READINESS CODE, GENERATING .

If no malfunction in wiring is detected and no voltage was present between contacts 1 + 3:

z

Replace engine control module, see ENGINE CONTROL MODULE (ECM), REPLACING .

Ignition coils with power output stage, checking

Special tools, test equipment and auxiliary items

z

Test box V.A.G 1598/31

z

Multimeter Fluke 83 (or equivalent)

z

Diode test lamp V.A.G 1527

z

Adapter set V.A.G 1594

z

Wiring diagram

Check conditions

z

Fuse 29 must be OK

Fig. 8: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

Fuse holder is located behind access panel at far left end of dash.
