1998-2004 ENGINE PERFORMANCE

Ignition-Glow Plug System, 1.8L APH - New Beetle

IGNITION/GLOW PLUG SYSTEM

IGNITION SYSTEM, SERVICING

Ignition system, general information

Safety precautions, see SAFETY PRECAUTIONS

Test data, spark plugs, see TEST DATA, SPARK PLUGS

Safety precautions

To prevent injuries to persons and/or damage to the fuel injection and ignition system, the following must be
noted:

z

Do not touch or disconnect ignition wiring when the engine is running or being turned at starter speed.

z

The ignition must be switched off before connecting or disconnecting injection or ignition system wiring
or tester cables.

z

If the engine is to be turned at starter speed, without starting:

Observe following if test and measuring instruments are required during a test drive:

NOTE:

z

Only the components which specifically relate to the ignition system are
dealt with here. For the other components of the injection and ignition
system, see MULTIPORT FUEL INJECTION (MFI) .

z

The engine control module is equipped with On Board Diagnostic (OBD).

z

Components marked with * are checked via the On Board Diagnostic
(OBD), see DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING
AND ERASING .

z

For trouble-free operation of the electrical components a voltage of at
least 11.5 V is necessary.

z

During some checks it is possible that the control module will recognize
and store a DTC. Therefore, after completing all checks and repairs the
DTC memory must be checked and, if necessary, erased, see DIAGNOSTIC
TROUBLE CODE (DTC) MEMORY, CHECKING AND ERASING .

WARNING:

z

When driving or riding in an airbag-equipped vehicle, NEVER hold
the scan tool or other test equipment in your hands or lap while in
motion. Objects between you and the airbag increase the risk of
injury in an accident.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L APH - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L APH - New Beetle



Ignition system components, removing and installing

The following list pertains to Fig. 1 .

1. Connector

z

Black, 4 pin

2. Ignition coils with power output stages -N70-, -N127-, -N291-, -N292-

z

Checking, see IGNITION COILS WITH POWER OUTPUT STAGE, CHECKING

z

Tighten mounting bolts to 10 Nm

z

Spark plug connector can be pulled off

3. Seal

z

Replace if damaged

4. Spark plug, 30 Nm

z

Remove and install with spark plug spanner 3122B

z

Type and electrode gap, see TEST DATA, SPARK PLUGS

5. Connector

z

Black, 3-pin

z

For Camshaft Position (CMP) sensor-G40-

6. 10 Nm

7. Camshaft Position (CMP) sensor - G40-*

z

Location, see COMPONENT LOCATIONS, OVERVIEW , engine compartment overview

z

Checking, see CAMSHAFT POSITION (CMP) SENSOR -G40-, CHECKING

8. 25 Nm

9. Washer

z

Conical

10. Hood

z

For Camshaft Position (CMP) sensor -G40-

z

When installing note in arrangement

11. 20 Nm

z

Tightening torque influences the function of the knock sensor

12. Knock sensor (KS) 1 -G61-*

z

Sensor and connector contacts are gold-plated

z

During a road test in an airbag-equipped vehicle, test equipment
must always be fastened to and operated from the rear seat by a
second technician.

NOTE:

Engine control module with connectors, see FUEL INJECTION SYSTEM
COMPONENTS, REMOVING AND INSTALLING , item 6.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L APH - New Beetle



z

Checking, see KNOCK SENSORS, CHECKING

13. Connector

z

Black, 2-pin

z

For Knock sensor (KS) 1 -G61-

z

Sensor and connector contacts are gold-plated

14. Ground wire

z

Only loosen or tighten with ignition switched off

15. 10 Nm

z

Only loosen or tighten with ignition switched off

16. Connector

z

Black, 2-pin

z

For Knock sensor (KS) 2 -G66-

z

Sensor and connector contacts are gold-plated

17. Knock sensor (KS) 2 -G66-*

z

Sensor and connector contacts are gold-plated

z

Checking, see KNOCK SENSORS, CHECKING



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L APH - New Beetle



Fig. 1: Identifying Ignition System Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect 4-pin connector -1- from power output stage for ignition coils (arrow).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L APH - New Beetle
