Fig. 21: Bending Up Tab On Inside Of Fuel Filler Pipe
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Insert end -A- of Ground strap through slot in tab up to bend -B- at other end of strap.

Fig. 22: Identifying Ground Strap
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Bend down tab on inside of fuel filler pipe. This will secure strap to end of tab.

z

Reinstall fuel filler cap.

CRASH FUEL SHUT-OFF

Function

Models with an airbag are equipped with a crash fuel shut-off system. This system reduces the danger of a fire
in a crash in that the fuel pump is switched off via the fuel pump relay. At the same time this system improves
starting of the engine. When the door is opened the fuel pump is activated for 2 seconds to build up pressure in
the fuel system.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



When opening the fuel system:

z

Observe safety precautions. See SAFETY PRECAUTIONS WHEN WORKING ON THE FUEL
SUPPLY SYSTEM
 .

z

Check activation of fuel pump relay using wiring diagram and V.A.G 1466 A: See appropriate SYSTEM
WIRING DIAGRAM article.

FUEL PUMP, CHECKING

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

3217 Union nut spanner

z

V.A.G 1318 Pressure gauge

z

V.A.G 1318/11 Adapter

z

V.A.G 1318/16 Hose adapter

z

V.A.G 1318/17 Adapter

z

V.A.G 1318/23 Adapter

Fig. 23: Identifying Special Tools
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1332 Torque wrench (40...200 N.m)

z

V.A.G 1348/3A Remote control with adapter cable V.A.G 1348/3-2

z

V.A.G 1527 B Diode test lamp

z

V.A.G 1594 A Adapter set

z

V.A.G 1715 Multimeter

z

Measuring container

z

Wiring diagram

Requirements



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Fuse 28 must be OK.

Fig. 24: Locating Fuse Box (Behind Access Panel At Far Left End Of Dash)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Battery voltage must be at least 11.5 V.

z

All electrical consumers, e.g. lights and rear window defogger must be switched off.

z

If the vehicle is equipped with air conditioning, this must be switched off.

z

On models with an automatic transmission selector lever in position "P" or "N"

Checking function and voltage supply

z

Remove cover from fuel delivery unit.

z

Briefly operate starter; fuel pump must be audibly starting.

z

Switch off ignition.

If the fuel pump does not run:

z

Remove cover in front of fuse holder.

z

Pull fuse No. 28 out of fuse holder.

z

Connect remote control V.A.G 1348/3A with adapter cable V.A.G 1348/3-2 to contact 28a to fuel pump
and battery positive (+).

NOTE:

Observe description of function of crash fuel shut-off. See CRASH FUEL
SHUT-OFF .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 25: Connecting Remote Control V.A.G 1348/3A To Fuel Pump Fuse Contact
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Operate remote control.

If fuel pump runs:

z

Check activation of fuel pump relay referring to wiring diagram:

See appropriate SYSTEM WIRING DIAGRAM article.

If fuel pump does not run:

z

Remove 4-pin connector from flange (arrow).

Fig. 26: Removing 4-Pin Connector From Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect diode test lamp V.A.G 1527 B with adapter cables from V.A.G 1594 A to outer contacts of
