Volkswagen New Beetle. Manual - part 1487





Fig. 10: Identifying 3217 Union Nut Spanner
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1332 Torque wrench (40-200 N.m)

Fig. 11: Identifying V.A.G 1332 Torque Wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

Requirements

z

Fuel tank must only be a maximum 1/2 full.

NOTE:

z

If necessary empty fuel tank with fuel extraction unit VAS 5190

z

Observe safety precautions before starting work. See SAFETY
PRECAUTIONS WHEN WORKING ON THE FUEL SUPPLY SYSTEM .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Check whether a coded radio is installed. If so, obtain anti-theft coding.

z

With ignition switched off disconnect battery Ground strap.

z

Fold rear seat bench forward.

z

Remove cover from fuel delivery unit.

z

Disconnect 4-pin connector as well as supply and return lines from flange (arrows).

Fig. 12: Disconnecting 4-Pin Connector, Supply And Return Lines From Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Seal lines to avoid contamination of fuel system.

z

Remove union nut with spanner 3217.

WARNING:

Fuel supply lines are under pressure! Before removing a hose connection
wrap a cloth around the connection. Then release pressure by carefully
pulling the hose off the connection.

NOTE:

Press buttons on hose couplings to disconnect.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 13: Removing Union Nut With Spanner
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Pull fuel delivery unit and seal out of opening in fuel tank.

Installing

Installation of the fuel delivery unit is performed in reverse order.

z

Adapt (match) engine control module to throttle valve control module. See COMPONENTS AND
FUNCTIONS, ADAPTING
 .

z

If fault memory has been erased or engine control module was disconnected from permanent positive,

NOTE:

If the delivery unit is to be replaced then drain old delivery unit before
disposal.

NOTE:

z

Insert seal for fuel delivery unit flange "dry" into opening of fuel tank.

z

Moisten seal with fuel only when installing fuel delivery unit flange or fuel
delivery unit.

z

When inserting fuel delivery unit be careful to ensure that the fuel gauge
sender does not become bent/deformed.

z

Note installed position of flange of fuel delivery unit: Marking on flange
must align with marking on fuel tank (arrows).

Fig. 14: Connecting 4-Pin Connector, Supply And Return Lines From
Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Ensure tight fit of fuel hoses.

z

After installing the fuel delivery unit, check that the supply, return and vent
lines are still clipped onto the fuel tank.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel Supply - 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



adapt respective components to engine control module (see COMPONENTS AND FUNCTIONS,
ADAPTING
 ), and generate readiness code again.
