Fig. 7: Removing Cover From Fuel Reservoir z Drain fuel tank, clean fuel filler neck and surrounding area. z Disconnect vent lines at filler neck z Press separated vent hose through opening in long member in fuel tank direction. z Remove mounting bolts on filler neck. z Fold rear bench seat forward. z Remove fuel gauge sensor cover plate. z Disconnect fuel supply and return lines front, right at fuel reservoir Fig. 8: Disconnecting Fuel Supply And Return Lines Front z Remove tensioning strap. While removing strap, support fuel tank with VAG 1383 A engine/transmission NOTE: Press buttons on hose couplings (arrows) to do this.
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Fuel System - 1.9L 4-Cyl. - ALH, New Beetle
|
