Fig. 67: Connecting Hand Multimeter Vag1526 To Measure Resistance Between Contacts 1 And 3 z Connect hand multimeter VAG1526 to measure resistance between contacts 2 and 3 of -V144 a Specification: 12.5 to 19.5 ohm If the specifications are not attained: z Replace Leak Detection Pump -V144-. z Check DTC memory. See Diagnostic Trouble Code (DTC) Memory, Checking And Erasing z Read readiness code. See Readiness Code, Displaying If the DTC memory has been erased or the Engine Control Module separated from permanent (battery) positive, See Diagnostic Trouble Code (DTC) Memory, Checking And Erasing
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)
|
