Check supply and return pipes on fuel delivery unit for leaks.

z

Repeat functional check.

Is the malfunction still present:

z

Remove rear right wheel housing liner.

See REAR WHEEL HOUSINGS LINER, ASSEMBLY OVERVIEW .

z

Check connecting pipes and hoses between Leak Detection Pump and EVAP canister. Replace if
necessary. See EVAPORATIVE EMISSION (EVAP) SYSTEM COMPONENTS, SERVICING .

z

Check wires and wire connections between EVAP canister and tank flap unit or tank ventilation valve for
proper seal. See EVAPORATIVE EMISSION (EVAP) SYSTEM, OVERVIEW .

z

Repeat functional check.

Is the malfunction still present:

z

Remove EVAP canister and check for cracks and leaks, replace if necessary.

z

Repeat functional check.

LEAK DETECTION PUMP (LDP) -V144-, CHECKING

Special tools and equipment

z

VAG 1715 Multimeter

z

VAG 1527 BLED test light

z

VAG 1594 A Adapter set

z

VAG 1598/22 Test box

z

Wiring diagram



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 59: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking voltage supply

Test conditions

z

Fuse No. 43 must be OK



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 60: Identifying Location Of Fuse No. 43
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

The battery voltage must be at least 11.5 V

Test sequence

z

Remove rear right wheel well liner.

See REAR WHEEL HOUSINGS LINER, ASSEMBLY OVERVIEW

z

Disconnect 3 pin connector from Leak Detection Pump -V144-.

NOTE:

Fuse box is located behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)



Fig. 61: Disconnecting 3 Pin Connector From Leak Detection Pump
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect LED test light VAG 1527 between connector terminal 3 (positive) and engine Ground.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)
