Volkswagen New Beetle. Manual - part 1467





Indicated on display: (1-4 = Display zones)

Fig. 44: V.A.G 1551 Scan Tool Display - Checking EVAP Canister Purge Regulator Valve (4 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

When the diagnosis is initiated by the Engine Control Module, the display in display zone 4 jumps from "Test
OFF" to "Test ON".

z

Run engine at idling speed until specification "EVAP OK" is displayed in display zone 4.

DISPLAY JUMPS FROM "TEST ON" TO "TEST OFF"

If "EVAP not OK" appears in display zone 4:

NOTE:

If the display jumps from "Test ON" to "Test OFF" during the test, rev up briefly
and the test will be repeated.

-

Display zones

1

2

3

4

Display group 70: Evaporative Emission (EVAP) system diagnosis (tank venting system)
Display

xxx. x %

xxx. x %

xxx %

Test OFF/Test ON

EVAP

(1)

 OK

EVAP n.OK

Indicated

EVAP canister purge

regulator valve opening

during diagnosis

oxygen sensor

control, Bank 1

EVAP canister purge

regulator valve

condition

Diagnosis condition

and Diagnosis result

Working
range

0.0-100.0%

-100.0-100.0%

0-199%

-

Specified
value

-

-

-

EVAP OK.

(1)

TEV means EVAP canister purge regulator valve.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)



z

Initiate output diagnostic test mode and activate EVAP Canister Purge Regulator Valve -N80-:

See Output Diagnostic Test Mode (DTM), Initiating

z

Check DTC memory.

See Diagnostic Trouble Code (DTC) Memory, Checking And Erasing

z

Read readiness code.

See Readiness Code, Displaying

If DTC memory has been erased or Engine Control Module separated from permanent (battery) positive,
readiness code must be generated again.

See Diagnostic Trouble Code (DTC) Memory, Checking And Erasing

If the specification "EVAP OK" is obtained:

z

Press --> button.

z

Press buttons -0- and -6- for function "End output" and confirm entry with -Q- button.

z

Switch ignition off.

EVAPORATIVE EMISSION (EVAP) SYSTEM, CHECKING FOR LEAKS

Special tools and equipment

z

VAG 1551 Scan Tool

Fig. 45: Identifying VAG 1551 Scan Tool
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)



z

VAG 1551/3 Cable

Fig. 46: Identifying VAG 1551/3 Cable
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Test conditions

z

Fuse No. 43 must be OK

Fig. 47: Identifying Location Of Fuse No. 43
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

No malfunction stored in DTC memory

NOTE:

The VAG 1552 vehicle system tester can be used instead of the VAG 1551
Scan Tool, however a print-out is not possible.

NOTE:

Fuse box is located behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)



See Diagnostic Trouble Code (DTC) Memory, Checking And Erasing

z

All electrical consumers, e.g. lights and rear window defroster must be switched off

z

If the vehicle is equipped with an air conditioner, this must be switched off

z

Throttle valve angle less than 4.1%. See display group 03, display zone 3

z

Coolant temperature less than 95° C. See display group 04, display zone 3

z

Intake air temperature less than 90° C. See display group 04, display zone 4

Functional check

z

Connect VAG 1551 Scan Tool (or VAG 1552 Scan Tool). Start engine and select Engine Control Module
with "Address word" 01.

Connecting scan tool and selecting Engine Control Module:

See V.A.G 1551 Scan Tool, Connecting And Selecting Engine Control Module

Indicated on display

Fig. 48: V.A.G 1551 Scan Tool Display - Checking EVAP System For Leak (1 Of 4)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press buttons -0- and -8- for function "Read Measuring Value Block" and confirm entry with -Q- button.

Indicated on display



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)
