Volkswagen New Beetle. Manual - part 1438





z

For filler neck

10. Vent line

z

Check for secure seating

11. Clamping washer

12. Heat shield

13. Fuel tank cover

14. 20 N.m plus an additional 90° (1/4 turn)

z

Always replace

15. Mounting strap

z

Note different lengths

16. Fuel tank

z

When removing, support with engine/transmission jack V.A.G 1383 A

z

Removing and installing, See FUEL TANK, REMOVING AND INSTALLING

17. Seal

z

Replace if damaged

z

When installing, insert seal "dry" into fuel tank opening

z

Moisten inner edges of seal with fuel when installing fuel gauge sensor

18. Fuel gauge sensor

z

Observe installed position on fuel tank, See Fig. 2

z

Removing and installing, See FUEL DELIVERY UNIT, REMOVING AND INSTALLING .

z

Check fuel gauge signal sensor, See FUEL GAUGE SENSOR, CHECKING

z

Check fuel pump. See FUEL PUMP, CHECKING ELECTRICALLY and DELIVERY
PRESSURE AND DELIVERY RATE OF FUEL PUMP, CHECKING
 .

19. Union nut

z

Remove and install with key 3217

20. Supply line

z

Black

z

To fuel filter, See FUEL FILTER, SERVICING

z

Clipped onto fuel tank

z

Check for secure seating

z

Press locking ring inward to release fuel line of fuel gauge sensor

21. Return hose

z

Blue

z

From fuel cooler, See FUEL COOLER, REMOVING AND INSTALLING

z

Clipped onto fuel tank

z

Check for secure seating

z

Press locking ring inward to release fuel line of fuel gauge sensor



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



22. Distance piece

23. Gravity/overflow valve

z

Check valve for through flow:

Valve vertical: Open,

Valve tilted 45°: Closed

24. 10 N.m

Fig. 1: Exploded View Of Fuel Tank Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Fuel gauge sensor, installed position

Mark on flange must align with mark on fuel tank (arrows).

Fig. 2: Mark On Fuel Gauge Sensor Flange Must Align With Mark On Fuel Tank
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



Vent valve, checking

Lever in rest position: Closed

Fig. 3: Checking Vent Valve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Lever pushed in direction of arrow: Open

FUEL FILTER, SERVICING

The flow direction is marked by an arrow on the fuel hose, the preheat valve and the fuel filter.

1. Return hose

z

To fuel cooler, See FUEL COOLER, REMOVING AND INSTALLING

z

Open lower spring-type clamp

z

Blue or with blue marking

z

Check for secure seating

2. Supply line

z

From fuel tank

z

White or with white marking

z

Check for secure seating

NOTE:

After installing fuel gauge sensor, check that the supply -2- and return lines -1-
are still clipped onto fuel tank.

NOTE:

Before installing breather valve, unscrew filler cap from fuel tank.

NOTE:

The following list refers to items in Fig. 4 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW



3. O-ring

z

Always replace

4. Securing clip

z

Replace if damaged

5. Protective plate

z

Note installation position

6. Control valve

z

Installed position: Arrow points toward fuel tank

z

When changing filter, remove retaining clip and protective plate and take off preheat valve with
hoses remaining connected. Replace O ring and coat with fuel before installing.

z

Below + 15°C:

Passageway to filter open

z

Over + 31°C:

Passageway to filter closed

7. Return line

z

From tandem pump

z

Open lower spring-type clamp

z

Check for secure seating

8. Supply line

z

To tandem pump

z

Check for secure seating

9. Fuel filter

z

Fill with diesel before installing

z

Flow direction is marked by arrows

z

Do not interchange connections

z

Replace if damaged

10. Tensioning bolt, 2 N.m

11. Bracket

z

Slide onto upper stop of fuel filter

12. Water drain plug

z

To bleed: remove retaining clip and protective plate and remove preheat valve with hoses
remaining connected

z

Loosen and allow approx. 100 cc of fluid to drain

13. Seal

z

Replace if damaged.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Fuel System - New Beetle, 1.9L 4-Cyl. - BEW
