Fig. 147: Identifying Switch A & B
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



CRUISE CONTROL SWITCH SPECIFICATIONS

If specifications not obtained:

z

Press --> button.

Display will appear as shown:

Checking requirements

Display zone 3

Switch B engaged at "OFF"

000000

Switch B at "OFF" before switch point

000001

Switch B at "ON"

000011

Switch B at "RES"

001011

Switch A pressed

000111

Brake pedal depressed

010011

Clutch pedal depressed

100011



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 148: Scan Tool Display - Checking Cruise Control System (Automatic Transmission) (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Press -0- and -6- buttons to select Function 06: "End output".

z

Press -Q- button to enter input.

z

Switch OFF ignition.

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.

Fig. 149: Connecting VAG 1598/22 Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open/short circuits between the Engine Control Module and the Cruise Control System
switches using Wiring diagram.

See appropriate System Wiring Diagram article.

Cruise Control System, activating and deactivating
